CAUTION PLATE & NAME PLATE (ENGINE)

11283PLATE, TURBOCHARGER CAUTION

main11294-64010i1CTL,2CTL..CV1#198308-198607

sub11294-64040

11288PLATE, ENGINE SYSTEM

main11288-88360i3SGELU..SV12198406-198607

11289PLATE, SPARK PLUG CAUTION

main11289-16010i3SGELU..SV12198606-198607

main11289-70010i3SGELU..SV12198410-198606

sub11289-16010

main11289-72010i3SGELU..SV12198406-198410

sub11289-73010

11291PLATE, ENGINE NAME

main11291-63020i1SLU..SV10198203-198406

1S

main11291-63050i1SILU..SV10198406-198607

1S-IL

main11291-64020i1CTL..CV10198308-198508

1C-T

main11291-64050i2CTL..CV11198508-198607

2C-T

main11291-74010i2SELU..SV11198208-198607

2S-E

main11291-88360i3SGELU..SV12198406-198607

3S-GEL

11294PLATE, ENGINE CAUTION, NO.2

main11294-54040i1CTL,2CTL..CV1#198412-198607

main11294-56010i1CTL..CV10198308-198412

sub11294-54040

11296PLATE, TIMING BELT CAUTION

main11296-54010i1CTL..CV10198308-198406

11297APLATE, ENGINE START CAUTION

main11297-64010i1CTL,2CTL..CV1#198308-198607

11299PLATE, IDLE ADJUSTING CAUTION

main11299-63030i1SLU..SV10198203-198207

sub11299-63031

main11299-63031i1SLU..SV10198207-198307

sub11299-63032

main11299-63032i1SLU..SV10198307-198406

main11299-74010i2SELU..SV11198208-198307

17700CPLATE, AIR CLEANER CAUTION (FOR ENGINE MODEL)

main17791-63010i1SLU,2SELU..SV1#198208-198307

main17791-63011i1SLU..SV10198203-198208

sub17791-63010

main17791-63020i1SLU..SV10198307-198406

17700DPLATE, ENGINE CAUTION

main11293-63050i1SILU..SV10198406-198607

main11293-64030i1CTL,2CTL..CV1#198308-198607

main11293-74040i2SELU..SV11198307-198607

main11293-74050i3SGELU..SV12198406-198607

17791LABEL, MAINTENANCE INFORMATION

main17791-64030i2CTL..CV11198602-198607

sub17791-55010

17792PLATE, ENGINE VACUUM HOSE INFORMATION

main17792-63020i1SLU..SV10198203-198212

main17792-63021i1SLU..SV10198212-198406

12 parts on this diagram · 1 diagram in section
