OIL PUMP, OIL COOLER & PIPE (MTM)

0001 1E56F,E57F 0002 1E56F 0003 1E56F 0004 1E56F

33129APIPE, MANUAL TRANSMISSION OIL, NO.1

main33129-12030iCT198,199,ST195..5F..(CZ,TZ,U,UL)199211

main33129-32010iST195..5F..TZG199502-199708

33129BPIPE, MANUAL TRANSMISSION OIL, NO.2

main33106-12040iCT198,199,ST195..5F199211

33129CGASKET(FOR MANUAL TRANSMISSION OIL PIPE)

main90430-09004iCT198,199,ST195..5F199211

33129EBUSH(FOR MANUAL TRANSMISSION OIL PIPE)

main90389-05012iCT198,199,ST195..5F199211

33139ACOVER, OIL PUMP(FOR MANUAL TRANSMISSION)

main33139-20010iCT198,199,ST195..5F..(CZ,TZ,U,UL)199211

main33139-20020iST195..5F..TZG199502-199708

33139BBOLT(FOR MANUAL TRANSMISSION OIL PUMP COVER)

main90119-06199iST195..5F..TZG199211-199708

33405AROTOR SUB-ASSY, MANUAL TRANSMISSION OIL PUMP

main33405-20020iCT198,199,ST195..5F199211

33407GEAR SUB-ASSY, MANUAL TRANSMISSION OIL PUMP DRIVE

main33407-12021iCT198199211-199805

main33407-12031iST195..5F..TZG199502-199708

main33407-12041iCT199,ST195..5F..(CZ,TZ,U,UL)199211

33408STRAINER SUB-ASSY, MANUAL TRANSMISSION OIL

main33408-20010iCT198,199,ST195..5F..(CZ,TZ,U,UL)199211-200004

sub33408-20011

main33408-20011iCT199200004

main33408-20020iST195..5F..TZG199502-199708

sub33408-20021

33408ARING, O (FOR MANUAL TRANSMISSION OIL STRAINER)

main96721-19012iCT198,199,ST195..5F199211

33409TUBE SUB-ASSY, MANUAL TRANSMISSION OIL COOLER

main33409-17010iCT198,199,ST195..5F..(CZ,TZ,U,UL)199211

33409AELBOW (FOR MANUAL TRANSMISSION OIL COOLER TUBE)

main90407-16017iCT198,199,ST195..5F199211

33409BRING, O (FOR MANUAL TRANSMISSION OIL COOLER TUBE ELBOW)

main90301-11006iCT198,199,ST195..5F199211

33469SEAT, RELIEF VALVE (FOR MANUAL TRANSMISSION OIL PUMP)

main33469-20010iCT198,199,ST195..5F..(CZ,TZ,U,UL)199211

33470PUMP ASSY, MANUAL TRANSMISSION OIL

main33470-12010iCT198,199,ST195..5F..(CZ,TZ,U,UL)199211-200004

sub33470-12011

main33470-12011iCT199200004

main33470-20030iST195..5F..TZG199502-199708

sub33470-20031

33470ABALL (FOR MANUAL TRANSMISSION OIL PUMP)

main90360-09001iST195..5F..TZG199502-199708

main90360-10003iCT198,199,ST195..5F..(CZ,TZ,U,UL)199211

33470BSPRING, COMPRESSION (FOR MANUAL TRANSMISSION OIL PUMP)

main90501-07062iST195..5F..TZG199502-199708

main90501-08092iCT198,199,ST195..5F..(CZ,TZ,U,UL)199211

main90501-08094iST195..5F..TZG199502-199708

33470DGASKET (FOR MANUAL TRANSMISSION OIL PUMP)

main90430-09004iCT198,199,ST195..5F199211

33593BHOLDER, SPRING (FOR MANUAL TRANSMISSION OIL PUMP)

main33593-20010iCT198,199,ST195..5F..(CZ,TZ,U,UL)199211

main33593-20020iST195..5F..TZG199502-199708

main33593-20030iST195..5F..TZG199502-199708

9011908649

main90119-08649

20 parts on this diagram · 4 diagrams in section
