DISC WHEEL & WHEEL CAP

0001 1 0002 1 0003 1

42601WHEEL, DISC

main42611-20870-01×4iAT190,CT190,ST190..EXS,GX,KYO,SELS,TYPE1199202-199601

main42611-20880-01×4iAT190..EXS;CT190,ST190..EXS,SELS,TYPE1; ST190..EXG;CT195,ST191,195199202-199402

main42611-20890×4iAT190,ST191..EXG,EXS,TYPE2;CT190,ST190..EXG,EXS,SELS,TYPE1; CT195,ST195199202-199402

42601AWHEEL, DISC (FOR SPARE)

main42611-20440iAT190,CT190,ST19#199202-199208

main42611-20870-01iCT190,ST190..KYO199211-199601

main42611-20880-01iAT190..EXS;CT190,ST190..EXS,SELS,TYPE1; ST190..EXG;CT195,ST191,195199202-199402

main42611-20890iST19#..EXS199305-199307

42601CNUT, HUB (FOR AXLE)

main90942-01007×20iCT190,ST190..KYO199211-199601

main90942-01021×20iAT190,CT19#,ST19#..EXG,EXS,GX,SELS,TYPE1,TYPE2199202-199601

main90942-01083×20iST19#..EXS199305-199307

42611GVALVE (FOR TUBELESS TIRE)

main90942-05009×4iAT190,CT19#,ST19#199202-199601

42611JVALVE (FOR TUBELESS TIRE SPARE)

main90942-05009iAT190,CT19#,ST19#199202-199601

5 parts on this diagram · 3 diagrams in section
