31105DSEAL, OIL, NO.1(FOR FRONT TRANSAXLE CASE)

main90311-25030i201908

31115CCASE, FRONT TRANSAXLE(MTM)

main31115-05031i201908-202010

main31115-05033i202010

3302CLUTCH HOUSING & TRANSMISSION CASE (MTM)

→ Go to FIG 33-02

41300CASE ASSY, FRONT DIFFERENTIAL, W/RING GEAR

main41300-02030i201908

41311EBEARING, TAPERED ROLLER (FOR FRONT DIFFERENTIAL CASE FRONT)

main90080-36143i201908

main90366-40117i201908

main90366-40149i202210-202504

main90366-50172i202006

41311FBEARING, TAPERED ROLLER (FOR FRONT DIFFERENTIAL CASE REAR)

main90366-44007i201908

main90366-44010i202210-202504

main90366-51007i202006

main90366-W0013i201908

41311GWASHER, PLATE (FOR FRONT DIFFERENTIAL CASE FRONT)

main90560-41003i201908

main90564-44070i202006

main90564-44071i202006

main90564-44072i202006

main90564-44073i202006

main90564-44074i202006

main90564-44075i202210-202504

main90564-44076i202210-202504

main90564-44077i202006

main90564-44078i202006

main90564-44079i202210-202504

main90564-44080i202210-202504

main90564-44081i202006

main90564-44082i202006

main90564-44083i202006

main90564-44084i202210-202504

main90564-44085i202210-202504

main90564-44086i202006

main90564-44087i202210-202504

main90564-44088i202210-202504

main90564-44089i202210-202504

main90564-44090i202210-202504

main90564-44091i202210-202504

main90564-44092i202210-202504

main90564-44093i202210-202504

main90564-44094i202210-202504

main90564-44095i202210-202504

main90564-44096i202210-202504

main90564-47001i201908

main90564-47002i201908

main90564-47003i201908

main90564-47004i201908

main90564-47005i201908

main90564-47006i201908

main90564-47007i201908

main90564-47008i201908

main90564-47009i201908

main90564-47010i201908

main90564-47011i201908

main90564-47012i201908

main90564-47013i201908

main90564-47014i201908

main90564-47015i201908

main90564-47016i201908

main90564-47017i201908

main90564-47018i201908

main90564-47019i201908

41311HWASHER, PLATE (FOR FRONT DIFFERENTIAL CASE REAR)

main90564-44039i201908

main90564-44040i201908

main90564-44041i201908

main90564-44042i201908

main90564-44043i201908

main90564-44044i201908

main90564-44045i201908

main90564-44046i201908

main90564-44047i201908

main90564-44048i201908

main90564-44049i201908

main90564-44050i201908

main90564-44051i201908

main90564-44052i201908

main90564-44053i201908

main90564-44054i201908

main90564-44055i201908

main90564-44056i201908

main90564-44057i201908

main90564-44058i201908

main90564-44059i201908

main90564-44060i201908

main90564-44061i201908

main90564-44062i201908

main90564-44063i201908

main90564-44064i201908

main90564-44065i201908

main90564-44066i201908

main90564-44067i201908

main90564-44068i201908

main90564-44069i201908

41311XOUTER RACE, TAPERED ROLLER BEARING (FOR DIFF. CASE FRONT)

main90080-36144i201908

41311YOUTER RACE, TAPERED ROLLER BEARING (FOR DIFF. CASE REAR)

main90366-W0014i201908

41331FGEAR, FRONT DIFFERENTIAL SIDE

main41331-0D070×2i201908

41341FPINION, FRONT DIFFERENTIAL

main41341-0D070×2i201908

41342APIN, STRAIGHT (FOR FRONT DIFFERENTIAL PINION SHAFT)

main90250-06058i201908

41342FSHAFT, FRONT DIFFERENTIAL PINION, NO.1

main41342-52060i201908

41351FWASHER, FRONT DIFFERENTIAL PINION THRUST

main41351-32010×2i201908

41361FWASHER, FRONT DIFFERENTIAL SIDE GEAR THRUST, NO.1

main41361-22020×2i201908

main41361-22030×2i201908

main41361-22040×2i201908

main41361-22140×2i201908

main41361-22150×2i201908

main41361-22160×2i201908

main41361-48010×2i201908

41361GWASHER, CONICAL SPRING(FOR CENTER DIFFERENTIAL SIDE GEAR)

main90208-35001×2i201908

4302FRONT DRIVE SHAFT

→ Go to FIG 43-02

FRONT AXLE HOUSING & DIFFERENTIAL
