IGNITION COIL & SPARK PLUG / GLOW PLUG

0001 1 0002 1 0003 1 0004 1

19100PPLUG, SPARK

main90919-01085i2ALU,3ALU,4AELU..AE8#198305-198704

main90919-01094i2ELU..EE80198604-198704

main90919-01121i4AGELU..AE82198410-198704

main90919-01122i4AGELU..AE82198410-198704

main90919-01125i2ELU..EE80..CTD,FXD198604-198704

main90919-01126i2ELU..EE80..CTD,FXD198604-198704

main90919-01139i2ELU..EE80198505-198604

W20EX-U11(DENSO)

19901CORD SET, COIL & SPARK, W/RESISTIVE

main90919-21350i4AGELU..AE82198410-198704

sub90919-29195

main90919-22105i2ALU,3ALU,4AELU..AE8#198305-198704

main90919-22168i2ELU..EE80198505-198704

sub90919-22167

19901BCORD, SPARK PLUG RESISTIVE, NO.1

main90919-12356i2ALU,3ALU,4AELU..AE8#198305-198704

main90919-12550i4AGELU..AE82198410-198704

main90919-12606i2ELU..EE80198505-198704

SUMITOMO

sub90919-12912

main90919-12607i2ELU..EE80198505-198704

YAZAKI

sub90919-12606

19901CCORD, SPARK PLUG RESISTIVE, NO.2

main90919-12357i2ALU,3ALU,4AELU..AE8#198305-198704

main90919-12551i4AGELU..AE82198410-198704

main90919-12569i2ELU..EE80198505-198704

SUMITOMO

sub90919-12775

main90919-12573i2ELU..EE80198505-198704

YAZAKI

sub90919-12569

19901DCORD, SPARK PLUG RESISTIVE, NO.3

main90919-12358i2ALU,3ALU,4AELU..AE8#198305-198704

main90919-12552i4AGELU..AE82198410-198704

main90919-12570i2ELU..EE80198505-198704

SUMITOMO

sub90919-12776

main90919-12574i2ELU..EE80198505-198704

YAZAKI

sub90919-12570

19901ECORD, SPARK PLUG RESISTIVE, NO.4

main90919-12359i2ALU,3ALU,4AELU..AE8#198305-198704

main90919-12553i4AGELU..AE82198410-198704

main90919-12571i2ELU..EE80198505-198704

SUMITOMO

sub90919-12777

main90919-12575i2ELU..EE80198505-198704

YAZAKI

sub90919-12571

19943PLATE, RESISTIVE CORD CLAMP SUPPORT NO.1

main19943-15020i3ALU..AE81..4F..DX198307-198401

main19943-15020i3ALU..AE81..DX198401-198505

W/KNOCK CONTROL

9046400073

main90464-00073

9046400074

main90464-00074

9046400082

main90464-00082

9165160816

main91651-60816

11 parts on this diagram · 4 diagrams in section
