DISC WHEEL & WHEEL CAP

0001 1 0002 1 0003 1

42601WHEEL, DISC

main42611-52450×4iNCP10#..G200509-200712

42601AWHEEL, DISC (FOR SPARE)

main42611-1A240iNCP10#,SCP100; NCP100,SCP100200509-200712

42601CNUT, HUB (FOR AXLE)

main90942-01033×16supersedes 90942-01007iNCP10#,SCP100200712-201008

42611GVALVE (FOR TUBELESS TIRE)

main90942-05009×4iNCP10#,SCP100200712

42611JVALVE (FOR TUBELESS TIRE SPARE)

main90942-05009iNCP10#,SCP100; NCP100,SCP100200509-200712

64770BCOVER ASSY, SPARE WHEEL

main64770-52110iNCP100,SCP100200511-200712

6 parts on this diagram · 3 diagrams in section
