FRONT AXLE HOUSING & DIFFERENTIAL

0001 1 0002 1 0003 1 0004 1 0005 1 0006 1

31105DSEAL, OIL, NO.1(FOR FRONT TRANSAXLE CASE)

main90043-11317iM10#,111;M110..5F199809

31105HSEAL, OIL, NO.2(FOR TRANSAXLE CASE)

main90043-10051iM10#,11#..5F199809

31115CCASE, FRONT TRANSAXLE(MTM)

main31115-97201iM100,110..5F199809-200209

main31115-97202iM100,110..5F200210

main31115-97401iM101,111..5F200005

33155STIFFENER, POWER TRAIN

main33155-97206iM100199809

main33155-97207iM110199809

3609TRANSFER CASE & EXTENSION HOUSING

→ Go to FIG 36-09

9004105233

main90041-05233

9004119726

main90041-19726

9004119731

main90041-19731

9161160855

main91611-60855

91612B1020

main91612-B1020

9161961245

main91619-61245

9161961265

main91619-61265

91651B0822

main91651-B0822

13 parts on this diagram · 6 diagrams in section
