PARKING BRAKE & CABLE

0001 1 0002 1 0003 1 0004 1 0005 1 0006 1

46101HANDLE SUB-ASSY, PARKING BRAKE CONTROL

main46201-55030iDA11#,DB10#,FA100,11#,FB100..5F196903-197003

main46201-55031iDA11#,FA100,11#,FB100..5F197003-197403

main46201-55040iFA100,11#,FC100..4F196903-198002

main46201-55041iFA100,115..RHD..4F198002-198207

main46201-55050iDA11#..RHD197704-198002

main46201-55060iDA11#,FA100,115..LHD..5F198002-198205

main46201-55061iDA11#,FA100,115..LHD198205-200112

main46201-55070iFA100,115..LHD..4F198002-198207

46110CPIN(FOR PARKING BRAKE HANDLE SET)

main90240-12045iDA11#,DB10#,FA100,11#,FB100,FC100196903-200112

46201ELEVER SUB-ASSY, PARKING BRAKE

main46210-55030iDB10#..RHD197003-197703

main46210-55031iDA11#,FA100,11#..RHD..5F197003-198002

main46210-55040iFA100,11#,FC100..4F196903-197003

main46210-55050iDA11#,DB10#..LHD; FA100,11#,FB100..LHD..5F196903-197003

main46210-55051iDA11#,FA100,115..LHD..5F197404-198002

main46210-55060iFA100,11#,FC100..RHD..4F197003-198002

main46210-55070iFA100,115..LHD..4F197404-198002

main46210-55080iDA11#..RHD..GEN198810-200112

main46210-55090iDA11#..LHD197704-198002

W/AIR SERVO BRAKE

main46210-55091iDA11#,FA100,115..LHD198204-200112

main46210-55100iDA115..ARL198810-200112

46205KNOB SUB-ASSY, PARKING BRAKE LEVER

main46205-55010iDA11#,DB10#,FA100,11#,FB100,FC100196903-198810

46217KNOB, PARKING BRAKE RELEASE ROD

main46217-55021iDA11#,DB10#,FA100,11#,FB100,FC100196903-197409

ISO

main46217-55030iDA11#,DB105,FA100,115197409-198810

46225ROD, PARKING BRAKE PAWL RELEASE

main46209-55011iFA100,11#,FC100..4F196903-197003

ISO

main46209-55021iDB10#..RHD197003-197703

main46209-55022iDA11#,FA100,115..LHD..5F197409-200112

main46209-55031iDA11#,DB10#,FA100,11#,FB100..LHD..5F196903-197003

ISO

main46209-55032iDA11#,FA100,11#,FB100..LHD..5F197003-197409

main46209-55040iFA100,11#,FC100..LHD..4F197003-198207

main46209-55050iDA115..ARL198810-200112

46225ASPRING, COMPRESSION(FOR PARKING BRAKE PAWL ROD)

main90501-12160iDA11#,DB10#,FA100,11#,FB100,FC100196903-198810

46225BRING, PARKING BRAKE PAWL RELEASE ROD

main90562-05014iDA11#..GEN198810-200112

46231SECTOR, PARKING BRAKE LEVER

main46203-55040iDA11#,DB10#,FA100,11#..RHD..5F196903-197003

main46203-55041iDA11#,FA100,11#..RHD..5F197003-197409

main46203-55042iDA11#,FA100,115..RHD..5F197409-197704

main46203-55043iDA11#,FA100,115..RHD..5F197704-200112

main46203-55050iFA100,11#,FC100..RHD..4F197003-198207

main46203-55060iDA11#,DB10#,FA100,11#,FB100..LHD..5F196903-197003

main46203-55061iDA11#,FA100,11#,FB100..LHD..5F197003-197409

main46203-55062iDA11#,FA100,115..LHD..5F197409-197704

main46203-55063iDA11#,FA100,115..LHD..5F197704-200112

main46203-55070iFA100,11#,FC100..LHD..4F197003-198207

46235BRACKET, PARKING BRAKE LEVER SUPPORT

main46235-55010iFA100,11#,FC100..RHD..4F196903-198207

main46235-55020iFA100,11#,FC100..LHD..4F196903-198207

46235ASPACER, PARKING BRAKE LEVER SUPPORT BRACKET

main90387-10102×2iDB10#196903-197703

main90560-10041iDA11#198405-200112

L=18

main90560-10106×2iDA11#,FA100,11#,FB100,FC100196903-200112

L=16

46311PAWL, PARKING BRAKE

main46311-55020iFA100,11#,FC100..4F196903-197409

main46311-55030iDA11#,DB10#,FA100,11#,FB100..5F196903-197003

main46311-55031iDA11#,FA100,11#,FB100..5F197003-197409

main46311-55032iDA11#,DB105,FA100,115197409-200112

46311BPIN, PARKING BRAKE PAWL PIVOT

main46226-55011iFA100,11#,FC100..4F197003-197107

main46226-55012iFA100,11#,FC100..4F197107-198207

main90240-10047iFA100,11#,FC100..4F196903-197003

main90240-10061iDA11#,DB10#,FA100,11#,FB100..5F196903-200112

46311CSPACER(FOR PARKING BRAKE PAWL PIVOT)

main90560-11107iDA11#,DB10#,FA100,11#,FB100,FC100196903-197003

main90560-12240iDA11#,FA100,11#,FB100..5F197003-197409

9020216019

main90202-16019

9112151055

main91121-51055

9112151070

main91121-51070

9121251032

main91212-51032

9411041000

main94110-41000

9451201000

main94512-01000

9461211001

main94612-11001

9461211200

main94612-11200

9461311000

main94613-11000

9538102020

main95381-02020

9538103018

main95381-03018

25 parts on this diagram · 6 diagrams in section
