WINDSHIELD WIPER

55795BBRACKET, FRONT WIPER MOTOR

main55795-36010iRZB54..30S;BB5#,TRB53,XZB53200012-200612

85070MOTOR & BRACKET ASSY, FRONT WIPER

main85070-0S010iTRB53,XZB53200707

main85070-36060iBB5#200012-200701

main85070-36070iRZB54..30S;TRB53,XZB53200012-200707

85150BLINK ASSY, WIPER

main85150-0S010iTRB53,XZB53200707

main85150-36030iTRB53,XZB53;BB54,RZB54..29S,30S200012-200707

85154PACKING, FRONT WIPER SHAFT

main85154-0S010iTRB53,XZB53200707

main85154-36020iBB5#,RZB5#..20S,23S,24S200012-200707

85168NUT, WINDSHIELD WIPER LINK PIVOT

main90099-05157iBB5#,RZB5#..20S,23S,24S200012-200612

85169WASHER, WINDSHIELD WIPER LINK PIVOT, NO.1

main90209-20001iBB5#,RZB5#200012-200612

85178NUT (FOR FRONT WIPER ARM SETTING)

main90179-08026iBB5#,RZB5#200012-200612

85192COVER, WINDSHIELD WIPER ARM

main85292-36020iBB5#,RZB5#200012-200612

85211BARM, FRONT WIPER, RH

main85211-36030iBB5#,RZB5#200012-200612

85212ABLADE, FR WIPER, RH

main85212-36050iBB5#,RZB5#200012-200612

85214ARUBBER, WIPER, RH

main85214-36020iBB5#,RZB5#200012-200612

85214BRUBBER, WIPER, LH

main85214-36020iBB5#,RZB5#200012-200612

85221BARM, FRONT WIPER, LH

main85221-36030iBB5#,RZB5#200012-200612

85222ABLADE, FR WIPER, LH

main85222-36050iBB5#,RZB5#200012-200612

9165140616

main91651-40616

9165160616

main91651-60616

16 parts on this diagram · 1 diagram in section
