DISC WHEEL & WHEEL CAP

0001 1 0002 1 0003 1

42601AWHEEL, DISC (FOR SPARE)

main42611-60190iUZJ100199801-200005

16X8JJ, #,TYPE A:REFER TO ILLUSTRATION

main42611-60270iUZJ100200005-200208

16X8JJ,TYPE A:REFER TO ILLUSTRATION

main42611-60280iUZJ100200008-200208

16X8JJ,TYPE A:REFER TO ILLUSTRATION,W(CHROME PLATED WHEEL)

main42611-60470iUZJ100200208-200505

17X8JJ, #,TYPE B:REFER ILLUST.

main42611-60480iUZJ100200505

17X8JJ, #,TYPE C:REFER ILLUST.

42601CNUT, HUB (FOR AXLE)

main90942-01103×20iUZJ100200505

42601FWHEEL, DISC (FOR FRONT)

main42611-60190×2iUZJ100199801-200005

16X8JJ, #,TYPE A:REFER TO ILLUSTRATION

main42611-60270×2iUZJ100200005-200208

16X8JJ,TYPE A:REFER TO ILLUSTRATION

main42611-60280×2iUZJ100200008-200208

16X8JJ,TYPE A:REFER TO ILLUSTRATION,W(CHROME PLATED WHEEL)

main42611-60470×2iUZJ100200505

17X8JJ, #,TYPE B:REFER ILLUST.

main42611-60480×2iUZJ100200208-200505

17X8JJ, #,TYPE C:REFER ILLUST.

42601RWHEEL, DISC (FOR REAR)

main42611-60190×2iUZJ100199801-200005

16X8JJ, #,TYPE A:REFER TO ILLUSTRATION

main42611-60270×2iUZJ100200005-200208

16X8JJ,TYPE A:REFER TO ILLUSTRATION

main42611-60280×2iUZJ100200008-200208

16X8JJ,TYPE A:REFER TO ILLUSTRATION,W(CHROME PLATED WHEEL)

main42611-60470×2iUZJ100200505

17X8JJ, #,TYPE B:REFER ILLUST.

main42611-60480×2iUZJ100200505

17X8JJ, #,TYPE C:REFER ILLUST.

42611GVALVE (FOR TUBELESS TIRE)

main90942-05009×4iUZJ100200505

main90942-05028×4iUZJ100200008-200208

W(CHROME PLATED WHEEL)

42611JVALVE (FOR TUBELESS TIRE SPARE)

main90942-05009iUZJ100199801-200208

main90942-05028iUZJ100200008-200208

W(CHROME PLATED WHEEL)

42652TIRE

main42652-60290×4iUZJ100..RHD199801-199811

275/70R16,*D/L

main42652-60291×4iUZJ100..RHD199811-200208

275/70R16 114T,*D/L

main42652-60310×4iUZJ100..LHD199801-199811

275/70R16,*D/L

main42652-60311×4iUZJ100..LHD199811-200008

275/70R16,*D/L

main42652-60312×4iUZJ100..LHD200008-200208

275/70R16,*D/L

main42652-60410×4iUZJ100..LHD199801-199811

275/70R16,*B/S

main42652-60411×4iUZJ100..LHD199811-200102

275/70R16,*B/S

main42652-60412×4iUZJ100..LHD200102-200208

275/70R16,*B/S

main42652-60570×4iUZJ100..LHD200008-200208

275/70R16,*Y/H

main42652-60720×4iUZJ100..RHD200208-200505

275/65R17 115T,*D/L

main42652-60750×4iUZJ100..LHD200505

275/65R17 115T,*D/L

main42652-60760×4iUZJ100..LHD200208-200505

275/65R17,*B/S

main42652-60830×4iUZJ100..LHD200208-200505

275/65R17,*Y/H

42652ATIRE (FOR SPARE)

main42652-60290iUZJ100..RHD199801-199811

275/70R16,*D/L

main42652-60291iUZJ100..RHD199811-200208

275/70R16 114T,*D/L

main42652-60310iUZJ100..LHD199801-199811

275/70R16,*D/L

main42652-60311iUZJ100..LHD199811-200008

275/70R16,*D/L

main42652-60312iUZJ100..LHD200008-200208

275/70R16,*D/L

main42652-60410iUZJ100..LHD199801-199811

275/70R16,*B/S

main42652-60411iUZJ100..LHD199811-200102

275/70R16,*B/S

main42652-60412iUZJ100..LHD200102-200208

275/70R16,*B/S

main42652-60570iUZJ100..LHD200008-200208

275/70R16,*Y/H

main42652-60720iUZJ100..RHD200505

275/65R17 115T,*D/L

main42652-60750iUZJ100..LHD200208-200505

275/65R17 115T,*D/L

main42652-60760iUZJ100..LHD200208-200505

275/65R17,*B/S

main42652-60830iUZJ100..LHD200505

275/65R17,*Y/H

8 parts on this diagram · 3 diagrams in section
