THROTTLE LINK & VALVE LEVER (ATM)

0001 1A442F 0002 1A442F 0003 1A442F 0004 1A750F

35501ROD SUB-ASSY, PARKING LOCK

main35501-36010iFZJ100..4FC..GCC200505

main35501-60020iUZJ100..5FC..CHI200506

35505LEVER SUB-ASSY, MANUAL VALVE

main35505-60020iFZJ100..4FC..CHI200506-200606

main35505-60050iUZJ100..5FC..CHI200309-200506

35505BSPACER (FOR MANUAL VALVE LEVER)

main90560-20008iUZJ100..ARL199801-200008

35505GPIN, SLOTTED SPRING (FOR MANUAL VALVE LEVER)

main90254-04012iUZJ100..ARL199801-200008

35506FSEAL, OIL (FOR MANUAL VALVE LEVER SHAFT)

main90311-12002×2iUZJ100..LHD..4FC;FZJ10#,HDJ100,HZJ105..4FC199801-200208

35556SHAFT, PARKING LOCK PAWL

main35556-36010iUZJ100..ARL199801-200008

main35556-60020iHDJ100,UZJ100..5FC..(ARL,GCC,GEN)200208-200505

35556FWASHER, PLATE (FOR PARKING LOCK PAWL SHAFT)

main90201-16012iUZJ100..ARL199801-200008

35557PAWL, PARKING LOCK

main35557-60030iUZJ100..LHD..4FC;FZJ10#,HDJ100,HZJ105..4FC199801-200208

main35557-60040iUZJ100..5FC..CHI200309-200506

35557ASPRING, TORSION (FOR PARKING LOCK PAWL)

main90508-30010iFZJ100..4FC..CHI199801

main90949-03123iHDJ100,UZJ100..5FC..(ARL,GCC,GEN)200505

35561SHAFT, MANUAL VALVE LEVER

main35561-60020iFZJ100..4FC..GCC200208-200505

main35561-60030iUZJ100..5FC..CHI200506

35572ALEVER, TRANSMISSION CONTROL SHAFT

main35572-60050iFZJ100..4FC..GCC200208-200505

35595BRACKET, PARKING LOCK PAWL

main35595-60020iUZJ100..ARL199801-200008

main35595-60030iHDJ100,UZJ100..5FC..(ARL,GCC,GEN)200505

9011908A43

main90119-08A43

9411050800

main94110-50800

9413000802

main94130-00802

9453100800

main94531-00800

16 parts on this diagram · 4 diagrams in section
