SWITCH & RELAY & COMPUTER

0001 1E/G,T/M,T/F & FR DIFF 0002 1E/G,T/M,T/F & FR DIFF 0003 1E/G ROOM RELAY 0004 1RH COWL RELAY 0005 1RH COWL RELAY 0006 1LH COWL RELAY 0007 1LH COWL RELAY 0008 1INSTRUMENT PANEL SW. 0009 1INSTRUMENT PANEL SW. 0010 1INSTRUMENT PANEL SW. 0012 1INSTRUMENT PANEL SW. 0014 1IGNITION & COMBINATION SW. 0015 1IGNITION & COMBINATION SW.(AI0016 1DOOR,ROOF SW. 0017 1FLOOR SW. 0018 1BACK DOOR SW.

83420GAGE ASSY, WATER TEMPERATURE SENDER

main83420-16040iFZJ80,HDJ80,HZJ80199208

YAZAKI

main83420-20020iFJ80,FZJ80,HDJ80,HZJ80199001-199208

83520GAGE ASSY,OIL PRESSURE SENDER

main83520-60010iFJ80,HZJ80..STD..ARL;FJ80,HDJ80,HZJ80..GX,VX199001-199112

sub83520-60011

main83520-60011iFZJ80..RHD..GX;FZJ80..VX..ARL;FZJ80..LHD..LUB;FZJ80..SOB..(GX,VX)199112-200103

main83520-60040iFZJ80..LUB;FZJ80..SOB..(GX,VX)199601

83530SWITCH ASSY, OIL PRESSURE (FOR ENGINE)

main83530-30060iFZJ80..STD..ARL;FZJ80,HZJ80..5F..(GX,STD)..GCC;FZJ80,HZJ80..STD..(ARL,GEN)..(CBR,DSL)199001-199803

sub83530-60030

main83530-60030iHZJ80..STD199803-200109

84210SWITCH ASSY, BACK-UP LAMP

main84210-60030iFZJ80,HDJ80,HZJ80..5F199001-200612

84210TSENSOR ASSY, SHIFT POINT

main84210-12040iFJ80,FZJ80..5F..GCC199001-199801

sub84210-52050

84222SWITCH, TRANSFER INDICATOR, NO.1

main84222-12010iFJ80,FZJ80,HDJ80,HZJ80199001-200612

84222BSWITCH, TRANSFER INDICATOR, NO.2

main84222-60080iFZJ80,HDJ80,HZJ80..4FC199001-199911

sub84222-60081

main84222-60081iFZJ80,HDJ80..4FC199911-200612

84222CSWITCH, TRANSFER INDICATOR, NO.3

main84222-12010iFJ80..STD..ARL;HZJ80..RHD..5F;HZJ80..LHD..(GX,VX);FJ80,FZJ80,HDJ80..GX,VX199001-200612

84222DSWITCH, TRANSFER INDICATOR, NO.4

main84222-12010iHDJ80..ARL;HDJ80..LHD;FZJ80..GX..EFI;FZJ80..RHD..STD;HZJ80..5F..(ARL,GEN);FZJ80..(GX,VX)..GEN..CBR;FZJ80,HZJ80..VX..(ARL,GCC)199001-200103

84540SWITCH ASSY, NEUTRAL START

main84540-60010iFJ80,HDJ80,HZJ80..4FC199001-199501

main84540-65010iFZJ80,HDJ80,HZJ80..4FC199501-200612

88620CTHERMO SWITCH ASSY

main88790-60050iHZJ80..GEN;HZJ80..GX..ARL;HZJ80..VX..GCC;HDJ80..4FC..ARL199001-200103

89423ASENSOR, MANIFOLD TEMPERATURE

main89423-60020iFJ80..EFI199001-199208

89428SWITCH, TEMPERATURE DETECT, NO.2

main89428-36030iHDJ80,HZJ80..4FC199208-200103

main89428-60070iFJ80..5F..GCC199001-199201

main89428-60080iFZJ80..GCC199201-199801

89428ESWITCH, TEMPERATURE, NO.2 (FOR TRANSMISSION)

main89428-26030iFJ80,HDJ80,HZJ80..4FC199001-199501

main89428-60090iFZJ80,HDJ80,HZJ80..4FC199501-200612

89491SENSOR, ENGINE OIL LEVEL

main89491-36080iHDJ80,HZJ80..ARL199208-199801

main89491-60010iFZJ80..ARL199208-199801

89593SENSOR, AIR CLEANER WARNING

main89593-26010iHDJ80,HZJ80199001-199811

main89593-60010iFJ80,FZJ80;HZJ80..GX..GCC199001-199208

89615SENSOR, KNOCK CONTROL

main89615-30050iFZJ80..EFI199208-199907

main89615-60010iFZJ80..EFI199907

8271112200WIRE, FUSE TO FUSE(FOR COMBUSTION HEATER)

main82711-12200

8271160020WIRE, FUSE TO FUSE(FOR COMBUSTION HEATER)

main82711-60020

8271560010BRACKET,WIRING HARNESS CLAMP

main82715-60010

9017904011

main90179-04011

9043018008

main90430-18008

9043027001

main90430-27001

9165140825

main91651-40825

9338515020

main93385-15020

9338516014

main93385-16014

26 parts on this diagram · 16 diagrams in section
