FRONT AXLE HOUSING & DIFFERENTIAL

0001 1 0002 1

43110HOUSING ASSY, FRONT AXLE

main43110-60023iFJ40,43,45196903-196908

FOR BALL JOINT TYPE

main43110-60024iFJ40,43,45196908-197009

ISO,FOR BALL JOINT TYPE

main43110-60025iFJ40,43,45197009-197109

FOR BALL JOINT TYPE,SINGLE M/C

main43110-60030iFJ40,43,45196903-196908

FOR BIRFIELD TYPE

main43110-60031iFJ40,43,45196908-197009

ISO,FOR BALL JOINT TYPE

main43110-60032iFJ40,43,45197009-197109

FOR BIRFIELD TYPE,SINGLE M/C

main43110-60041iFJ55196903-196908

FOR BALL JOINT TYPE

main43110-60042iFJ55196908-197109

FOR BALL JOINT TYPE,SINGLE M/C

main43110-60050iFJ55196903-196908

FOR BIRFIELD TYPE

main43110-60051iFJ55196908-197109

FOR BIRFIELD TYPE,SINGLE M/C

main43110-60080iFJ40,43,45197109-197111

FOR BALL JOINT TYPE

main43110-60090iFJ40..LHD197101-197109

FOR BIRFIELD TYPE,TANDEM M/C

main43110-60091iFJ40,43,45,HJ45197111-197210

main43110-60092iBJ4#,FJ4#,HJ45197210-197509

main43110-60093iBJ4#197901-198007

main43110-60100iFJ55197109-197111

FOR BALL JOINT TYPE

main43110-60110iFJ55197109-197111

FOR BIRFIELD TYPE

main43110-60111iFJ55197111-197210

main43110-60112iFJ55197210-197509

main43110-60113iFJ55197509-197901

main43110-60114iFJ55197901-198007

main43110-60120iFJ4#,HJ45197509-197901

main43110-60121iFJ4#,HJ45197901-198007

43110APLUG SUB-ASSY, DRAIN

main33104-30010iFJ40,43,45,55196903-196908

main90341-18057iBJ4#,FJ40,43,45,55,HJ45196908-198007

ISO

43110BGASKET, DRAIN

main12157-10010iBJ4#,FJ40,43,45,55,HJ45196903-198007

43110CPLUG (FOR FRONT AXLE HOUSING)

main90341-18014iFJ40,43,45,55196903-196908

main90341-18049iBJ4#,FJ40,43,45,55,HJ45196908-198007

ISO

43110DGASKET (FOR FRONT AXLE HOUSING PLUG)

main12157-10010iBJ4#,FJ40,43,45,55,HJ45196903-198007

43110EPLUG, BREATHER (FOR FRONT AXLE HOUSING)

main90930-03019iBJ4#,FJ40,43,45,55,HJ45196903-198007

43130HOUSING ASSY, FRONT AXLE, NO.2

main43130-60011iFJ42196903-196908

main43130-60012iFJ42196908-197009

ISO

main43130-60013iFJ42197009-197109

main43130-60014iFJ42197109-197203

43130APLUG, TIGHT (FOR FRONT AXLE HOUSING)

main96411-04000×2iFJ42196903-197203

43411ABUSH, SOLID (FOR FRONT AXLE INNER SHAFT)

main90999-70064iFJ40,43,45,55196903-197111

RH.

main90999-70065iFJ40,43,45,55196903-197111

LH.

43411DSEAL, TYPE T OIL (FOR FRONT DRIVE SHAFT)

main90311-33085×2iBJ4#,FJ40,43,45,55,HJ45196903-198007

43600CARRIER ASSY, FRONT AXLE

main41110-60015iBJ4#,HJ45;FJ4#,55..ARL,GEN197501-197801

R=37:9=4.111

main41110-60016iBJ4#,HJ45;FJ4#,55..ARL,GEN197801-198007

R=37:9=4.111

main41110-60025iFJ4#,55..EUR,GEN197608-197801

R=37:10=3.700

main41110-60026iFJ4#,55..EUR,GEN197801-198007

R=37:10=3.700

main41110-60906iFJ40,43,45,55196903-197401

R=37:10=3.700

main41110-60907iFJ40,43,45,55,HJ45196903-197401

R=37:9=4.111

43600ABOLT, STUD (FOR FRONT AXLE DIFFERENTIAL CARRIER SETTING)

main90116-10103×8iBJ4#,FJ40,43,45,55,HJ45196903-198007

L=37,S=12 & 25,L=37,S=12&25

main90116-10104×2iBJ4#,FJ40,43,45,55,HJ45196903-198007

L=50,S=12 & 18,L=50,S=12&18

43611GASKET, FRONT AXLE DIFFERENTIAL CARRIER

main42181-36010iBJ4#,FJ40,43,45,55,HJ45196903-198007

9411051000

main94110-51000

9451201000

main94512-01000

15 parts on this diagram · 2 diagrams in section
