SWITCH & RELAY & COMPUTER

0001 1ENGINE & TRANSMISSION 0002 1ENGINE & TRANSMISSION 0003 1ENGINE ROOM 0004 1ENGINE ROOM 0005 1ENGINE ROOM RELAY BLOCK 0006 1ENGINE ROOM RELAY BLOCK 0007 1COWL 0008 1COWL 0009 1INSTRUMENT PANEL 1/2 0010 1INSTRUMENT PANEL 2/2 0011 1INSTRUMENT PANEL 1/2 0012 1INSTRUMENT PANEL 2/2 0013 1CONSOLE BOX 0014 1STEERING 0015 1SEAT 0016 1DOOR & ROOF 0017 1FLOOR & BACK DOOR

82715BRACKET,WIRING HARNESS CLAMP

main82715-6AW50iVJA252..ARL202402

82715YBRACKET, WIRING HARNESS CLAMP, NO.3

main82715-76291iTJH252202403

main8946A-60140iVJA252202402

83520GAGE ASSY,OIL PRESSURE SENDER

main83520-60070iTJH252,VJA252202402

84540SWITCH ASSY, NEUTRAL START

main84540-60080iTJH252,VJA252202402

89422ASENSOR, WATER TEMPERATURE

main89422-33040iTJH252202403

89425SENSOR, EXHAUST GAS TEMPERATURE

main89425-60330iTJH252202403

89425ASENSOR, EXHAUST GAS TEMPERATURE, NO.2

main89425-60340iTJH252202403

89429FSENSOR, TEMPERATURE

main89429-12010iTJH252,VJA252202402

89467BSENSOR, AIR FUEL RATIO

main89467-60180iVJA252202402

main89467-60270iTJH252202403

89467CSENSOR, AIR FUEL RATIO, NO.2

main89467-60190iVJA252202402

main89467-60280iTJH252202403

8946ABRACKET, EXHAUST SENSOR CLAMP

main8946A-60360iTJH252202403

8946AABRACKET, EXHAUST SENSOR CLAMP, NO.2

main8946A-60350iTJH252202403

89481BSENSOR, DIFFERENTIAL PRESSURE

main89481-48010iTJH252202403

89491SENSOR, ENGINE OIL LEVEL

main89491-33052iTJH252202403

main89491-50082iVJA252202402

89615SENSOR, KNOCK CONTROL

main89615-20090×2iVJA252202402

main89615-78010iTJH252202403

9011906A23

main90119-06A23

9011908C62

main90119-08C62

9043012031

main90430-12031

9046814044

main90468-14044

9046815007

main90468-15007

9155180835

main91551-80835

9167180612

main91671-80612

9167180620

main91671-80620

9167180820

main91671-80820

24 parts on this diagram · 17 diagrams in section
