CAUTION PLATE
11285FLABEL, COOLANT SYSTEM CAUTION
TYPE A:REFER ILLUST.
TYPE B:REFER ILLUST.
ENGINE-FOR EURO 6C CONFORMITY,TYPE C:REFER ILLUST.
11297CLABEL, ENGINE SERVICE INFORMATION, NO.2
11298BLABEL, EMISSION CONTROL INFORMATION
PHILIPPINES SPEC&EXHAUST EMISSION CONTROL-EURO 4
PHILIPPINES SPEC&ENGINE-FOR EURO 4 CONFORMITY
PHILIPPINES SPEC
28897APLATE, BATTERY CAUTION
GEORGIA,AZORES,TAJIKISTAN,ARMENIA SPEC&COLD AREA SPEC
74511BPLATE, NAME
SAUDI ARABIA SPEC
74515CLABEL, THEFT WARNING INFORMATION
main74515-33020×2iGRJ150..6F..GEN;GRJ150..LHD..6FC;GDJ150,LJ150..GEN;KDJ150,TRJ15#..GCC,GEN201708-202312
ANTI-THEFT SYSTEM-*IM & SECURITY HORN
74567APLATE, E.C.E APPROVED NUMBER
74596DLABEL, PASSENGER AIRBAG CAUTION, NO.2
main74596-53012×2iKDJ150..GCC,GEN;GRJ150..6F..GEN;GRJ150..LHD..6FC;GDJ150,TRJ150..5F,6FC201708-201908
REAR SEAT-SLIDEWALK-IN & 5:5 DOUBLE FLAT POWER&SRS AIR BAG-W(*DRP&KNEE&CURTAIN(RRNO.1&NO.2 SEAT))
74751LABEL, TIRE PRESSURE INFORMATION
SPECIAL EDITION
VX-L PACKAGE&TIRE & DISC WHEEL-265/60R18, 7.5J, ALUMINUM
VX-L PACKAGE&TIRE & DISC WHEEL-265/55R19, 7.5J, ALUMINUM
88723HLABEL, COOLER SERVICE CAUTION
KUWAIT SPEC
KUWAIT SPEC&AIR CONDITIONER-DUAL(AUTO),WITH(*RR AIR DUCT=PNC 87217G)
KUWAIT SPEC&AIR CONDITIONER-DUAL(AUTO),WITH(*RR AIR DUCT=PNC 87217G)&COOL BOX-WITH
10 parts on this diagram · 4 diagrams in section
