CAUTION PLATE & NAME PLATE (ENGINE)

11278PLATE, ENGINE EMISSION IDENTIFICATION

11283PLATE, TURBOCHARGER CAUTION

11284PLATE, ENGINE BOLT INFORMATION

11291PLATE, ENGINE NAME

main11291-35030i22R..RU85198808-199409

11293PLATE, ENGINE CAUTION & ENGINE NAME

main11293-78010i1W..WU9#198808-198910

main11293-78020i1W..WU9#198910-199305

main11296-73010i4Y..YU62..TW1;4Y..YU62..WT..GEN;4Y..YU63,71,82..LHD198808-199109

CHINA SPEC

main11296-73011i4Y..YU62..TW1;4Y..YU62..WT..GEN;4Y..YU63,71,82..LHD199109-199505

CHINA SPEC

11293BLABEL, TUNE-UP SPECIFICATION INFORMATION

11296PLATE, TIMING BELT CAUTION

11297PLATE, ENGINE CAUTION, NO.3

main11297-71010i4Y..YU6#,71,8#198808-199505

11298PLATE, EMISSION CONTROL INFORMATION

main11298-73170i4Y..YU62..ARL198808-199109

main11298-73171i4Y..YU62..ARL199109-199204

11299PLATE, IDLE ADJUSTING CAUTION

main11299-35010i22R..RU85198808-199505

17700CPLATE, AIR CLEANER CAUTION (FOR ENGINE MODEL)

main90917-07108i22R,1W,4Y..RU85,WU9#,YU6#,71,8#198808-199505

17700DPLATE, ENGINE CAUTION

main11293-35050i22R..RU85198808-199505

main90917-07109i1W..WU9#198808-199305

23923PLATE, FUEL SEDIMENTER CAUTION

main23923-56010i1W..WU9#198808-199305

13 parts on this diagram · 1 diagram in section
