REAR FLOOR PANEL & REAR FLOOR MEMBER

0001 1 0002 1

51790STEP ASSY, REAR FLOOR

main58303-92120iBU20,RU20..LHD..VSG..GEN197711-198408

W/PARALLEL SEAT

main58303-92615iBU20,JU20,RU20..LHD..(HRF,SRF)197708-198408

main58304-92120iBU20,RU20..RHD..VSG197711-198204

W/PARALLEL SEAT

main58304-92605iBU20,RU20..RHD..SRF197708-198408

51790APLATE SUB-ASSY, REAR STEP, RH

main58303-95400iBU32,HU30,RU20,30..TW1197708-198204

main58309-95400iBU32,RU20,30..TW1198204-198408

51790BPLATE SUB-ASSY, REAR STEP, LH

main58303-95400iBU32,HU30,RU20,30..TW1197808-198204

main58304-95400iHU30,RU20,30..TW1197708-197808

main58309-95400iBU32,RU20,30..TW1198204-198408

58306ARAIL SUB-ASSY, FLOOR SIDE, INNER

main58305-95402iBU32,RU20,30..TW1198204-198408

RH

main58306-95400iBU32,RU20,30..TW1198204-198408

LH

58397BSTAY, REAR STEP, RH

main58397-95400iBU32,RU20,30..TW1198204-198408

58398BSTAY, REAR STEP, LH

main58398-95400iBU32,RU20,30..TW1198204-198408

58450COVER ASSY, BATTERY SERVICE HOLE

main65305-92605iBU20,JU20,RU20..HRF,SRF197708-198408

FR

main65305-95401iBU32,HU30,RU20,30..TW1197708-198408

main65306-92605iBU20,JU20..LHD..V197708-198408

RR

58450APACKING, BATTERY SERVICE HOLE COVER

main58414-95400iBU32,RU20,30..TW1198311-198408

L=1180

main65352-92605iBU20,JU20,RU20..HRF,SRF197708-198408

FR(12V & 24V)

main65352-92607iBU20,JU20..LHD..V197803-198408

RR(24V)

main65352-95401iBU32,HU30,RU20,30..TW1197708-198311

L=1100

58461COVER, TRANSMISSION SERVICE HOLE

main58405-95402iHU30..TS198010-198104

FR

main58409-95402iHU30..TS197708-198010

main58409-95403iHU30..TS..IV3;BU20,JU20,RU20,30..TW1,VSG,VSP197708-198008

main58409-95404iBU20,RU20..HRF,SRF198008-198408

main58409-95405iBU32,HU30,RU20,30..TW1198008-198408

main58409-95406iHU30..TS198010-198104

RR

58465PACKING, TRANSMISSION SERVICE HOLE COVER, NO.1

main58465-95402iRU20..BUS;BU20,JU20..HRF,SRF;BU32,RU20,30..TW1,VSG,VSP197708-198408

main58478-95400iHU30..TS197708-198104

58465APACKING, TRANSMISSION COVER

main58476-95400iHU30..TS197708-198010

LH

main58476-95401iHU30..TS198010-198104

LH

main58477-95400iHU30..TS197708-198010

RH

main58477-95401iHU30..TS198010-198104

RH

58466CPACKING, TRANSMISSION SERVICE HOLE COVER, NO.2

main58486-95400×2iHU30..TS198010-198104

58467CPACKING, FRONT TRANSMISSION COVER, NO.3

main58487-95400iHU30..TS198010-198104

58945PACKING, TRANSMISSION SERVICE HOLE COVER

main58466-95402iRU20..BUS;BU20,JU20..HRF,SRF;BU32,HU30,RU20,30..TW1,VSG,VSP197708-198408

58945APACKING, TRANSMISSION SERVICE HOLE COVER, NO.1

main64138-95400×2iRU20..BUS;BU20,JU20..HRF,SRF;BU32,HU30,RU20,30..TW1,VSG,VSP197708-198408

64133ACOVER, HEADER PANEL

main64133-95400×2iBU32,HU30,RU20,30..TW1197708-198408

64134DPACKING, HEADER PANEL COVER

main64134-95400×2iBU32,HU30,RU20,30..TW1197708-198408

64134ESEAL, HEADER PANEL COVER

main64138-95400×2iBU32,HU30,RU20,30..TW1197708-198408

74741BSPRING, STARTING HANDLE SUPPORT

main74716-95A00×2iBU20,JU20,RU20..HRF,SRF197708-198408

main74741-95401×2iBU32,HU30,RU20,30..TW1197901-198408

75255COVER, STEP PLATE REAR, NO.1

main75253-95401×2iBU32,HU30,RU20,30..TW1197708-198204

main75253-95402×2iBU32,RU20,30..TW1198204-198408

75256COVER, STEP PLATE REAR, NO.2

main75254-95400×2iBU32,HU30,RU20,30..TW1197708-198204

9165141025

main91651-41025

9166540616

main91665-40616

9324016010

main93240-16010

9351014008

main93510-14008

9461110800

main94611-10800

26 parts on this diagram · 2 diagrams in section
