POWER TAKE-OFF LEVER & LINK

38901DLEVER SUB-ASSY, VALVE CONTROL

main38901-37030-B0iXZU305..T3200404-200610

MD.CHARCOAL,TRIM1#

main38901-37040-B0iBU303,WU300,XZU320..LHD..WT..IV3200308-200610

MD.CHARCOAL,TRIM1#

main38901-37110-B0iXZU305..T3200501-200610

W(STABILIZER BAR),MD.CHARCOAL,TRIM1#

38901HKNOB, VALVE CONTROL LEVER

main46217-20020-B1iXZU305..T3200404-200610

MD.CHARCOAL,TRIM1#

38902BBRACKET SUB-ASSY, VALVE CONTROL LEVER

main38902-37040iBU303..RHD..WT..IV3200306-200610

main38902-37050iXZU320200212-200610

main38902-37120iXZU305..T3200501-200610

W(STABILIZER BAR)

38902CBUSH (FOR VALVE CONTROL LEVER)

main90386-12034×2iBU303..RHD..WT..IV3200306-200610

38914APIPE, VALVE CONTROL LEVER

main38914-37010iXZU320200212-200610

38930ACABLE ASSY, PUSH PULL

main38930-37460iXZU305..T3200501-200610

38961BRACKET, CABLE CLAMP, NO.1

main38962-37360iXZU305..T3200501-200610

38962BRACKET, CABLE CLAMP, NO.2

main38962-37410iXZU305..T3200501-200610

38976CCLAMP, PUSH PULL CABLE

main38976-37030×2iXZU305..T3200501-200610

NO.2

main38976-37100iXZU305..T3200501-200610

NO.1

38982ACLAMP, PUSH PULL CABLE, NO.2

main38976-37040iXZU305..T3200501-200604

main38976-37041iXZU305..T3200605-200610

38987CLAMP, CABLE PUSH PULL

main38976-37050iXZU305..T3200501-200610

8413POWER TAKE-OFF CONTROL

→ Go to FIG 84-13

4737137040BRACKET, CONNECTOR

main47371-37040

8271537B40BRACKET,WIRING HARNESS CLAMP

main82715-37B40

9011908103

main90119-08103

9017908241

main90179-08241

9046400840

main90464-00840

9046812029

main90468-12029

9094901B95

main90949-01B95

91511B0855

main91511-B0855

9155180814

main91551-80814

9165160616

main91651-60616

91651B0825

main91651-B0825

9415010801

main94150-10801

24 parts on this diagram · 1 diagram in section
