BATTERY & BATTERY CABLE

28800BATTERY

main28800-42041×2iS05C,15BFTE..XZU30#,342..20T200010-200212

55D23L,YUASA

main28800-42042×2iS05C,15BFTE..XZU30#,342..20T200010-200212

55D23L

main28800-54020×2iS05C..XZU302,307..WT200010-200206

80D26L

main28800-56080×2i15BFTE..XZU300..20T200108-200212

55D23L,FURUKAWA

main28800-64182×2iS05C..XZU302,307,342;15BFTE..XZU300,320,330,340..30T,40T199907-200212

95D31L

28800ATERMINAL, BATTERY POSITIVE

main90982-05042iS05C,15BFTE..XZU30#,320,330,34#199907-200212

28800CCABLE, BATTERY TO STARTER(FOR BATTERY TO MAIN SWITCH)

main82122-37140i15BFTE..XZU300,330,340199907-200212

main82122-37150i15BFTE..XZU320199907-200212

main82122-37220iS05C..XZU302,307200010-200206

STARTER=TYPE A:FIG 19-04

main82122-37230iS05C..XZU307200010-200206

STARTER=TYPE B:FIG 19-04

main82122-37240iS05C..XZU342200010-200206

28800DCOVER, CONNECTOR(FOR BATTERY TERMINAL)

main82821-37071iS05C,15BFTE..XZU30#,320,330,34#200005-200212

28800FCABLE, BATTERY TO BATTERY

main82123-37040iS05C,15BFTE..XZU30#,320,330,34#199907-200212

28800JTERMINAL, BATTERY NEGATIVE

main90982-06028iS05C,15BFTE..XZU30#,320,330,34#199907-200212

8271110460WIRE, FUSE TO FUSE(FOR COMBUSTION HEATER)

main82711-10460

827153V470BRACKET,WIRING HARNESS CLAMP

main82715-3V470

827153V510BRACKET,WIRING HARNESS CLAMP

main82715-3V510

8272937630

main82729-37630

9011908827

main90119-08827

9017908227

main90179-08227

9020110282

main90201-10282

91651B0825

main91651-B0825

14 parts on this diagram · 1 diagram in section
