DISC WHEEL & WHEEL CAP

42601CNUT, HUB (FOR AXLE)

main90942-01007×20iLH11..IDN198211-198507

main90942-01027×20iLH11,RH11..ARL,EUR,GEN198211-198507

42601DWEIGHT, BALANCE (FOR DISC WHEEL)

main90942-03017iLH11,RH11198211-198507

20G,T=8,20G

main90942-03020iLH11,RH11198211-198507

30G,T=10,30G

main90942-03022iLH11,RH11198211-198507

40G,T=9.5,40G

main90942-03025iLH11,RH11198211-198507

50G,T=9.5,50G

main90942-03027iLH11,RH11198211-198507

60G,T=9.5,60G

main90942-03029iLH11,RH11198211-198507

70G,T=9.5,70G

main90942-03031iLH11,RH11198211-198507

80G,T=9.5,80G

main90942-03041iLH11,RH11198211-198507

10G,T=7.5,10G

42601FWHEEL, DISC (FOR FRONT)

main42601-26170×2iLH11,RH11..GEN,IDN198211-198507

4.5J-14

main42601-26180×2iLH11,RH11..ARL,EUR,GEN198211-198507

14X4.5J,5.5J-14

42601RWHEEL, DISC (FOR REAR)

main42601-26170×3iLH11,RH11..GEN,IDN198211-198507

4.5J-14

main42601-26180×3iLH11,RH11..ARL,EUR,GEN198211-198507

14X4.5J,5.5J-14

42603ORNAMENT SUB-ASSY, WHEEL HUB

main42603-26030×4iLH11,RH11..ARL,EUR,GEN198211-198507

42611ATIRE TUBE SET OR TUBELESS TIRE

main42605-26080×5iLH11,RH11..GEN198211-198507

185R14-6,W/TUBE,*(D),*(T),*(Y)

main42605-26110×5iLH11,RH11..ARL198211-198507

185R14-8,W/TUBE,*(D),*(T)

main42605-26140×2iLH11,RH11..GEN,IDN198211-198507

6.00-14-6,FR,W/TUBE

main42605-26150×3iLH11,RH11..GEN; LH11,RH11..GEN,IDN198211-198507

6.00-14-8,RR,W/TUBE; 6.00-14-8,W/TUBE

main42605-26170×5iLH11,RH11..GEN198405-198507

185R14-6,W/TUBE,*(B)

main42605-26180×5iLH11,RH11..ARL198405-198507

185R14-8,W/TUBE,*(B)

main42652-26010×5iLH11,RH11..EUR198211-198507

185R14C-6

main42652-26020×5iRH11..LHD..EUR198211-198507

185R14C-8

42611GVALVE (FOR TUBELESS TIRE)

main90942-05009×5iLH11,RH11..EUR198211-198507

42621CAP, WHEEL

main42621-26110×4iLH11..IDN198211-198507

8 parts on this diagram · 1 diagram in section
