HEATING & AIR CONDITIONING - COOLER PIPING

0001 1W(CONDENSER FAN) 0002 1W(CONDENSER FAN) 0003 1FRONT W/O(SCX TUBE) 0006 1FRONT W/O(SCX TUBE) 0008 1FRONT W(SCX TUBE) 0010 1FRONT W/O(SCX TUBE) 0011 1FRONT W(SCX TUBE) 0012 1FRONT 0013 1FRONT W/O(SCX TUBE) 0014 1FRONT W(SCX TUBE) 0015 1FRONT 0016 1REAR

16793CLABEL, COOLING FAN CAUTION

main16793-31070i1GRFE,2TRFE..GGN155,TGN156,166..EPT,GCC201908-202101

88453FAN, COOLING (FOR CONDENSER)

main88453-60010iGGN155,165,TGN156,166..EPT,GCC201601-202101

88454ASHROUD, FAN

main88454-0K040iGGN155,165,TGN156,166..IDNSU..GCC; TGN156..IDNSU..6FC..L..GCC201601-202007

ASIA COLD COUNTRY SPEC

main88454-0K050iGGN155,165,TGN156,166..(EPTSU,THSUV)..(EPT,GCC)201601-202101

88550MOTOR ASSY, BLOWER (FOR CONDENSER)

main88550-12160iGGN155,165,TGN156,166..EPT,GCC201601-202101

88590BLOWER ASSY, W/SHROUD

main88590-0K050iGGN155,165,TGN156,166..IDNSU..GCC; TGN156..IDNSU..6FC..L..GCC201601-201907

ASIA COLD COUNTRY SPEC

main88590-0K051iGGN155,TGN156,166..IDNSU..GCC; TGN156..IDNSU..L..GCC201908-202007

ASIA COLD COUNTRY SPEC

main88590-0K060iGGN155,165,TGN156,166..(EPTSU,THSUV)..(EPT,GCC); TGN156..THSUV..6FC..L201601-201907

ASIA COLD COUNTRY SPEC

main88590-0K061iGGN155,TGN156,166..(EPTSU,THSUV)..(EPT,GCC)201908-202101

88723BLABEL, COOLER SERVICE CAUTION

main88723-20081iGGN155,165,TGN156,166..EPT,GCC; TGN156..6FC..L..GCC201601-201908

ASIA COLD COUNTRY SPEC

827112B640WIRE, FUSE TO FUSE(FOR COMBUSTION HEATER)

main82711-2B640

8889771010VALVE, COOLER MAGNET

main88897-71010

8889771020VALVE, COOLER MAGNET

main88897-71020

8889771030VALVE, COOLER MAGNET

main88897-71030

9009904117

main90099-04117

9009904119

main90099-04119

90119T0202

main90119-T0202

13 parts on this diagram · 12 diagrams in section
