DISC WHEEL & WHEEL CAP
42601AWHEEL, DISC (FOR SPARE)
16X7JJ, #,TIRE & DISK WHEEL-P265/70R16 7JJ ALMINUM,TYPE C:REFER ILLUST.; 16X7JJ, #,TYPE C:REFER ILLUST.
16X7JJ, #,TIRE & DISC WHEEL-P265/70R16 7JJ ALMINUM,TYPE C:REFER ILLUST.; 16X7JJ, #,TYPE C:REFER ILLUST.
16X7JJ, #,TIRE & DISK WHEEL-P265/70R16 7JJ ALMINUM,TYPE D:REFER ILLUST.; 16X7JJ, #,TYPE D:REFER ILLUST.
16X7JJ, #,TIRE & DISC WHEEL-P265/70R16 7JJ ALMINUM,TYPE D:REFER ILLUST.; 16X7JJ, #,TYPE D:REFER ILLUST.
17X7.5JJ, #,TIRE & DISK WHEEL-P265/65R17 7.5JJ ALMINUM,TYPE E:REFER ILLUST.
17X7.5JJ, #,TIRE & DISK WHEEL-P265/65R17 7.5JJ ALMINUM,TYPE E:REFER ILLUST.
17X7.5JJ, #,TIRE & DISK WHEEL-P265/65R17 7.5JJ ALMINUM,TYPE F:REFER ILLUST.
17X7.5JJ, #,TIRE & DISK WHEEL-P265/65R17 7.5JJ ALMINUM,TYPE F:REFER ILLUST.
42601CNUT, HUB (FOR AXLE)
TIRE & DISK WHEEL-P265/65R17 7.5JJ ALMINUM,TYPE A:REFER ILLUST.; TIRE & DISK WHEEL-P265/70R16 7JJ ALMINUM,TYPE A:REFER ILLUST.; TYPE A:REFER ILLUST.
42601FWHEEL, DISC (FOR FRONT)
16X7JJ, #,TIRE & DISK WHEEL-P265/70R16 7JJ ALMINUM,TYPE C:REFER ILLUST.; 16X7JJ, #,TYPE C:REFER ILLUST.
16X7JJ, #,TIRE & DISK WHEEL-P265/70R16 7JJ ALMINUM,TYPE C:REFER ILLUST.; 16X7JJ, #,TYPE C:REFER ILLUST.
16X7JJ, #,TIRE & DISK WHEEL-P265/70R16 7JJ ALMINUM,TYPE D:REFER ILLUST.; 16X7JJ, #,TYPE D:REFER ILLUST.
16X7JJ, #,TIRE & DISC WHEEL-P265/70R16 7JJ ALMINUM,TYPE D:REFER ILLUST.; 16X7JJ, #,TYPE D:REFER ILLUST.
17X7.5JJ, #,TIRE & DISK WHEEL-P265/65R17 7.5JJ ALMINUM,TYPE E:REFER ILLUST.
17X7.5JJ, #,TIRE & DISK WHEEL-P265/65R17 7.5JJ ALMINUM,TYPE E:REFER ILLUST.
17X7.5JJ, #,TIRE & DISK WHEEL-P265/65R17 7.5JJ ALMINUM,TYPE F:REFER ILLUST.
17X7.5JJ, #,TIRE & DISC WHEEL-P265/65R17 7.5JJ ALMINUM-A,TYPE F:REFER ILLUST.
42601RWHEEL, DISC (FOR REAR)
16X7JJ, #,TIRE & DISK WHEEL-P265/70R16 7JJ ALMINUM,TYPE C:REFER ILLUST.; 16X7JJ, #,TYPE C:REFER ILLUST.
16X7JJ, #,TIRE & DISC WHEEL-P265/70R16 7JJ ALMINUM,TYPE C:REFER ILLUST.; 16X7JJ, #,TYPE C:REFER ILLUST.
16X7JJ, #,TIRE & DISK WHEEL-P265/70R16 7JJ ALMINUM,TYPE D:REFER ILLUST.; 16X7JJ, #,TYPE D:REFER ILLUST.
16X7JJ, #,TIRE & DISK WHEEL-P265/70R16 7JJ ALMINUM,TYPE D:REFER ILLUST.; 16X7JJ, #,TYPE D:REFER ILLUST.
17X7.5JJ, #,TIRE & DISK WHEEL-P265/65R17 7.5JJ ALMINUM,TYPE E:REFER ILLUST.
17X7.5JJ, #,TIRE & DISK WHEEL-P265/65R17 7.5JJ ALMINUM,TYPE E:REFER ILLUST.
17X7.5JJ, #,TIRE & DISK WHEEL-P265/65R17 7.5JJ ALMINUM,TYPE F:REFER ILLUST.
17X7.5JJ, #,TIRE & DISC WHEEL-P265/65R17 7.5JJ ALMINUM-A,TYPE F:REFER ILLUST.
42611GVALVE (FOR TUBELESS TIRE)
42611JVALVE (FOR TUBELESS TIRE SPARE)
42652TIRE
265/65R17 112S,*B/S,TIRE & DISK WHEEL-P265/65R17 7.5JJ ALMINUM
265/65R17 112S,*B/S,TIRE & DISC WHEEL-P265/65R17 7.5JJ ALMINUM-A
265/65R17,*D/L,TIRE & DISC WHEEL-P265/65R17 7.5JJ ALMINUM-A
265/65R17,*D/L,TIRE & DISC WHEEL-P265/65R17 7.5JJ ALMINUM-A
42652ATIRE (FOR SPARE)
265/65R17 112S,*B/S,TIRE & DISK WHEEL-P265/65R17 7.5JJ ALMINUM
265/65R17 112S,*B/S,TIRE & DISC WHEEL-P265/65R17 7.5JJ ALMINUM-A
265/65R17,*D/L,TIRE & DISC WHEEL-P265/65R17 7.5JJ ALMINUM-A
265/65R17,*D/L,TIRE & DISC WHEEL-P265/65R17 7.5JJ ALMINUM-A
8 parts on this diagram · 4 diagrams in section
