INDICATOR

81930LAMP ASSY, HEATER CONTROL INDICATOR, NO.1

main81930-89106iRN46..EUR,GEN;RN46..ARL..IV3;LN30,40,RN3#,40,41197808-198008

sub81930-89108

main81930-89108iLN3#,4#,RN3#,4#198008-198108

main81930-89110iLN3#,4#,RN3#,4#198108-198312

81930ALAMP ASSY, HEATER CONTROL INDICATOR, NO.2

main81930-89111iLN30,40,RN30,41..(4F,5F)..ECB198108-198312

81930BBULB, HEATER CONTROL INDICATOR LAMP

main90981-11014iLN3#,4#,RN3#,4#198108-198312

14V 1.4W,12V 1.4W,INNER

main90981-11018iLN3#,4#,RN3#,4#197808-198108

12V 1.2W W/O SOCKET,12V 1.4W

main90981-11018iLN3#,4#,RN3#,4#198108-198312

12V 1.2W W/O SOCKET,12V 1.4W,OUTER

81941PLATE, HEATER CONTROL NAME

main55519-89103iLN30,40,RN30..(4F,5F)..ECB198108-198312

W/HEATER

main55519-89104iLN3#,4#,RN3#,4#..RHD..GEN198108-198307

W/*BV

main55519-89105iLN30,40,RN30,40..STD..RCB198201-198403

W/HEATER & COOLER

main55519-89105iLN3#,4#,RN3#,4#..RHD..(ARL,GEN,SA)198108-198201

W/HEATER OR *BV & COOLER

main55519-89106iLN3#,4#,RN3#,4#..LHD..(EUR,GEN,ME)198108-198307

W/HEATER

main55519-89107iLN3#,4#,RN3#,4#..LHD..(GEN,ME,PHL)198108-198307

W/*BV

main55519-89108iLN3#,4#,RN3#,4#..LHD..(GEN,ME)198201-198307

W/HEATER & COOLER

sub55942-89108

main55519-89108iLN3#,4#,RN3#,4#..LHD..(GEN,ME)198108-198201

W/HEATER OR *BV & COOLER

sub55942-89108

main55519-89109iLN3#,4#,RN3#,4#..RHD..GEN198201-198403

W/*BV & COOLER

main55519-89110iLN3#,4#,RN3#,4#..LHD..(GEN,ME)198201-198307

W/*BV & COOLER

9018904042

main90189-04042

9354054014

main93540-54014

6 parts on this diagram · 1 diagram in section
