STEERING WHEEL

45100WHEEL ASSY, STEERING

main45100-2B290-C0i200008-200307

3-SPOKE,URETHANE,W/O(*80),BLACK,TRIM14,15

main45100-42080-C0i200005-200307

3-SPOKE,URETHANE,BLACK,TRIM1#; 3-SPOKE,URETHANE,BLACK,TRIM14,15

main45100-42100-C0i200005-200307

3-SPOKE,LEATHER,BLACK,TRIM1#; 3-SPOKE,LEATHER,BLACK,TRIM14,15

main45100-42200-C0i200307-200511

3-SPOKE,URETHANE,BLACK,TRIM1#

main45100-42210-C0i200307-200511

3-SPOKE,LEATHER,BLACK,TRIM1#

main45100-42220-C0i200307-200511

3-SPOKE,URETHANE,W(CRUISE CONTROL),BLACK,TRIM1#

main45100-42230-C0i200307-200511

3-SPOKE,LEATHER,W(CRUISE CONTROL),BLACK,TRIM1#

45130BUTTON ASSY, HORN

main45130-42010-C0i200008-200307

W/O(*80),BLACK,TRIM14,15

main45130-42080-C0i200005-200307

BLACK,TRIM1#; BLACK,TRIM14,15

main45130-42110-C0i200307-200511

TYPE A:REFER TO ILLUSTRATION,BLACK,TRIM1#

main45130-42120-C0i200307-200511

TYPE B:REFER TO ILLUSTRATION,BLACK,TRIM1#

main45130-42140-C0i200307-200511

W(AUDIO SWITCH),BLACK,TRIM1#

45188SCREW, STEERING WHEEL PAD ATTACHING

main45188-60010×2i200307-200511

L=18

main90148-60007×2i200005-200307

L=18

45201PNUT, STEERING WHEEL SET

main90179-12071i200005-200307

4 parts on this diagram · 4 diagrams in section
