85031BVALVE SUB-ASSY, WASHER

main85321-26020×2i202007-202112

85035NOZZLE SUB-ASSY, WASHER

main85381-30220×2i202201-202403

ANGLE 0

main85381-30230×2i202501

ANGLE -2

main85381-30240×2i202401-202412

ANGLE +2

8504REAR WASHER

→ Go to FIG 85-04

85301INLET SUB-ASSY, WASHER

main85301-0A020i202401

main85301-0A040i202201-202403

main85301-0A100i202501

85310MOTOR AND PUMP ASSY, WINDSHIELD WASHER

main85330-0A030i202007-202111

main85330-0A040i202404-202412

85330JAR ASSY, WINDSHIELD WASHER

main85315-0A040i202007-202111

main85315-0A050i202010-202410

main85315-0A060i202404-202412

main85315-0A130i202110-202411

85330ABUSH, WINDSHIELD WASHER JAR

main90099-32089i202007-202111

85332CAP, WINDSHIELD WASHER JAR

main85316-0A020i202201-202403

main85386-0A020i202007-202410

85336EPACKING, WINDSHIELD WASHER INLET HOSE

main85336-30160i202007-202212

85348GJOINT, WINDSHIELD WASHER HOSE, NO.2

main85375-02330i202007-202111

85355VALVE, WINDSHIELD WASHER HOSE

main85321-0A010i202111-202410

main85321-28020i202010-202411

main85348-14390i202007-202402

85371HOSE, WINDSHIELD WASHER (FROM MOTOR TO JOINT)

main90068-33020i202411

L=250

main90068-33389i202007-202212

L=250

main90099-33080i202404-202412

L=1450(*H,L=250)

85371GPROTECTOR, FRONT WASHER

main85389-26080×2i202401-202512

85372HOSE, WINDSHIELD WASHER (FROM JOINT TO JOINT), NO.1

main90068-33393i202007-202111

L=2300

85372BHOSE, WINDSHIELD WASHER (FROM JOINT TO JOINT), NO.2

main90068-33360×2i202501

L=375

85373HOSE, WINDSHIELD WASHER (FROM JOINT TO NOZZLE)

main90068-33019×2i202007-202111

L=40

main90068-33258×2i202010-202411

L=430

85387CLAMP NO.1 (FOR WINDSEIELD WASHER)

main85371-12040×5i202007-202111

8271135750WIRE, FUSE TO FUSE(FOR COMBUSTION HEATER)

main82711-35750

8537132020HOSE, WINDSHIELD WASHER (FROM MOTOR TO JOINT)

main85371-32020

8537152110HOSE, WINDSHIELD WASHER (FROM MOTOR TO JOINT)

main85371-52110

9011906767

main90119-06767

90119T0144

main90119-T0144

9046707214

main90467-07214

90467T0039

main90467-T0039
