DISC WHEEL & WHEEL CAP

0001 1 0002 1

04423FITTING KIT, TIRE PRESSURE MONITOR OR BALANCER VALVE

main04423-48010×4iGAYA16202408

42601WHEEL, DISC

main4261A-52040×4iGAYA16202408

19X8.5J,#,TYPE A:REFER ILLUST.

42601BBOLT, HUB (FOR AXLE)

main90942-02103×20iGAYA16202408

42603ORNAMENT SUB-ASSY, WHEEL HUB

main42603-53140×4iGAYA16202408-202506

*ALU,TYPE A:REFER ILLUST.

42607VALVE SUB-ASSY, TIRE PRESSURE MONITOR

main42607-78020×4iGAYA16202408

42607DVALVE, TIRE PRESSURE MONITOR

main90942-05050×4iGAYA16202408

42611UCAP, TIRE VALVE

main90942-05048×4iGAYA16202408

7 parts on this diagram · 2 diagrams in section
