CAUTION PLATE (EXTERIOR & INTERIOR)

0001 1EXTERIOR 0002 1INTERIOR

11285ALABEL, COOLANT SYSTEM NOTICE

main11285-11020i4KM..KPX10202005

16793ELABEL, COOLING FAN CAUTION

main16793-36030i4KM..KPX10202005

47997CLABEL, ACCUMULATOR CAUTION, NO.1

main47997-76010iKPX10202005

74515APLATE, THEFT WARNING

main74515-06020×2iKPX10202005-202007

74573DLABEL, ELECTRIC VEHICLE BATTERY CAUTION

main74573-F4010iKPX10202005

74573ELABEL, ELECTRIC VEHICLE BATTERY CAUTION, NO.2

main74573-F4030iKPX10202005

74751LABEL, TIRE PRESSURE INFORMATION

main42661-F4180supersedes 42661-F4200iKPX10202005

SPARE TIRE-T145/70D18 STEEL

88723HLABEL, COOLER SERVICE CAUTION

main88723-F4090iKPX10202005

G9275LABEL, BATTERY CAUTION, NO.1

mainG9275F4010iKPX10202005

G92A1LABEL, HYBRID COOLANT SYSTEM INFORMATION

mainG92A176010iKPX10202005

10 parts on this diagram · 2 diagrams in section
