REAR DISC BRAKE CALIPER & DUST COVER

04466PAD KIT, DISC BRAKE, REAR

main04466-50220iAZSH32202405

MARK NBK D6504H

04479ACYLINDER KIT, DISC BRAKE, REAR

main04479-62020iAZSH32202405

04946SHIM KIT, ANTI SQUEAL(FOR REAR DISC BRAKE)

main04946-62010iAZSH32202405

04948FITTING KIT, DISC BRAKE, REAR

main04948-50070iAZSH32202405

31478CCAP, BLEEDER PLUG(FOR REAR DISC BRAKE)

main31478-14010×4iAZSH32202405

4601PARKING BRAKE & CABLE

→ Go to FIG 46-01

47547CPLUG, BLEEDER(FOR REAR DISC BRAKE)

main47547-50010×4iAZSH32202405

47743BSPRING, ANTI-RATTLE, NO.2(FOR REAR DISC BRAKE)

main47718-50210×2iAZSH32202405

47748DSPRING, ANTI-RATTLE, NO.1(FOR REAR DISC BRAKE)

main47717-50210×2iAZSH32202405

47810ABOLT, HEXAGON(FOR REAR CALIPER)

main90105-12396×4iAZSH32202405

47830CYLINDER ASSY, DISC BRAKE, REAR RH

main47830-50200iAZSH32202405

47831PISTON, REAR DISC BRAKE

main47731-50180×4iAZSH32202405

47835PIN, REAR DISC BRAKE PAD GUIDE

main47835-50140×4iAZSH32202405

47843CLIP, REAR DISC BRAKE PIN HOLD

main47843-50140×2iAZSH32202405

47848SPRING, ANTI-RATTLE, NO.1(FOR REAR DISC BRAKE)

main47848-50150×2iAZSH32202405

47850CYLINDER ASSY, DISC BRAKE, REAR LH

main47850-50200iAZSH32202405

16 parts on this diagram · 1 diagram in section
