THROTTLE LINK & VALVE LEVER (ATM)

0001 1 0002 1

35520CABLE ASSY, THROTTLE

main35520-22020iMS111..RHD..ATM197909-198008

main35520-30021iLS110..4FC197909-197911

main35520-30022iLS110..4FC197911-198008

main35520-30023iLS110..4FC198008-198307

main35520-30030iMS112..ATM198008-198307

35520BRING, O(FOR THROTTLE CABLE)

main90301-09004iLS110,MS112..ATM198305-198307

main90301-09063iLS110,MS11#..ATM197909-198305

35523CLAMP, THROTTLE CABLE

main35523-22020iMS11#..ATM197909-198206

main35523-30010iLS110..4FC197909-198307

35527INSULATOR, THROTTLE CABLE HEAT

main35527-22011iMS11#..ATM197909-198206

main35527-24020iMS112..ATM198206-198307

9046106052

main90461-06052

9111141014

main91111-41014

9165140610

main91651-40610

9451101000

main94511-01000

9622110710

main96221-10710

9 parts on this diagram · 2 diagrams in section
