THROTTLE LINK & VALVE LEVER (ATM)

0001 1U760E,U761E 0002 1UB80E

3312

35501ROD SUB-ASSY, PARKING LOCK

main35501-33020iASV7#201810-202110

main35501-33030iAXVA70202111

35506SHAFT SUB-ASSY, MANUAL VALVE LEVER

main35503-48010iAXVA70202111

NO.2

main35506-33011iASV7#201810-202110

main35506-33040iAXVA70202111-202205

NO.1,AISIN:SEE 35-01

main35506-33041iAXVA70202205

NO.1,AISIN:SEE 35-01

35506FSEAL, OIL (FOR MANUAL VALVE LEVER SHAFT)

main90301-09173iAXVA70201810-202110

main90311-12002iASV71201810-202110

(J)

35506JSPRING, RETAINER (FOR MANUAL VALVE LEVER SHAFT)

main90524-09002iASV71201810-202110

(J)

main90524-09004iAXVA70201810-202110

35556SHAFT, PARKING LOCK PAWL

main35556-33020iASV7#201810-202110

main35556-48040iAXVA70201810-202110

AISIN:REFER 35-01

35556CSPRING, TORSION (FOR PARKING LOCK PAWL SHAFT)

main90508-21008iASV71201810-202110

(J)

35556HSHAFT, PARKING LOCK PAWL

main35556-33030iASV7#201810-202110

35557PAWL, PARKING LOCK

main35557-33040iAXVA70201810-202110

main35557-73010iASV7#201810-202110

35558CLAMP, PAWL SHAFT

main35558-33020iASV71201810-202110

(J)

35572ALEVER, TRANSMISSION CONTROL SHAFT

main35572-33020iASV71201810-202110

(J)

main35572-48050iAXVA70201810-202110

main35572-48051iAXVA70202111

35596PLATE, PAWL STOPPER

main35596-33020iAXVA70201810-202110

main35596-73010iASV7#201810-202110

35596ABOLT (FOR PAWL STOPPER PLATE)

main91551-80816×2iASV7#201810-202110

*8-1.25PX16-13.5

35598SLEEVE, PARKING LOCK

main35598-33010iASV71201810-202110

(J)

main35598-48040iAXVA70201810-202110

8401

9155180816

main91551-80816

9413000802

main94130-00802

9451200800

main94512-00800

18 parts on this diagram · 2 diagrams in section
