CAUTION PLATE & NAME PLATE (ENGINE)

11278PLATE, ENGINE EMISSION IDENTIFICATION

main11278-16040i1MZFE..MCV20199608-199808

main11278-16050i1MZFE..MCV20..ARL199808

11289PLATE, SPARK PLUG CAUTION

main11289-20010i1MZFE..MCV20..ARL199608

main11289-62020i1MZFE..MCV20..GCC199810

11291PLATE, ENGINE NAME

main11291-20010i1MZFE..MCV20..ARL199608

11298PLATE, EMISSION CONTROL INFORMATION

main11298-20120i1MZFE..MCV20..ARL199608

16701GLABEL, CAUTION

main88723-20080i1MZFE..MCV20199608-199704

main88723-20081i1MZFE..MCV20199704

1356410010LABEL, TIMING BELT REPLACEMENT INFORMATION

main13564-10010

6 parts on this diagram · 1 diagram in section
