DISC WHEEL & WHEEL CAP

0001 1 0002 1

42603ORNAMENT SUB-ASSY, WHEEL HUB

main42603-32010×4iCV10,SV1#198210-198406

TYPE A

main42603-32020×4iCV10,SV1#..GL,GLI198210-198406

ALUMI WHEEL,TYPE B

main42603-32030×4iCV1#,SV1#198406-198610

TYPE C

main42638-32040×4iCV1#,SV1#..GL,GLI198406-198610

ALUMI WHEEL,TYPE D

42611ATIRE TUBE SET OR TUBELESS TIRE

main42652-12390×5iSV11..ARL198303-198410

185/70SR13

main42652-12610×5iSV11..ARL198410-198508

185/70HR13

main42652-14140×5iSV10198210-198610

165SR13,*(B),*(D),*(T)

main42652-14180×5iCV10,SV1#..EUR198210-198508

185/70HR13

main42652-14290×5iSV10198210-198610

165SR13,*(Y)

main42652-20140×5iSV10..RHD198409-198610

165SR13,IRELAND SPEC

main42652-32090×5iSV10..LHD198408-198610

165SR13,WEST GERMANY SPEC

42611GVALVE (FOR TUBELESS TIRE)

main90942-05009×5iCV1#,SV1#198210-198610

42621CAP, WHEEL

main42621-32010×4iCV1#,SV1#..(GL,GLI)..EUR198406-198610

42624RING, WHEEL CAP

main42624-32020×4iCV1#,SV1#..GL,GLI198406-198610

5 parts on this diagram · 2 diagrams in section
