85035NOZZLE SUB-ASSY, WASHER

main85381-30220i201810-202209

ANGLE 0

main85381-30230×2i201409-201510

ANGLE -2

main85381-30240×2i201409-201510

ANGLE +2

8505HEADLAMP CLEANER

→ Go to FIG 85-05

85301INLET SUB-ASSY, WASHER

main85301-24050i201409-201510

85310MOTOR AND PUMP ASSY, WINDSHIELD WASHER

main85330-60190i201810-202209

85319DPACKING, FRONT WASHER

main85319-33230i201409-201510

85330JAR ASSY, WINDSHIELD WASHER

main85355-24020supersedes 85315-30390i201510-201608

main85355-24060i201810-202206

HEADLAMP CLEANER-WITH(SYNCHRONIZATION TO FIRST WIPER)

main85355-24061i202209

HEADLAMP CLEANER-WITH(SYNCHRONIZATION TO FIRST WIPER)

85330ABUSH, WINDSHIELD WASHER JAR

main85336-60300i201409-201510

85332CAP, WINDSHIELD WASHER JAR

main85316-24120i201409-201510

main85316-24121i202009

85336EPACKING, WINDSHIELD WASHER INLET HOSE

main85336-42320i201409-201510

85348JOINT, WINDSHIELD WASHER HOSE, NO.1

main85349-89122i201409-201510

85348DJOINT, WINDSHIELD WASHER ELBOW, NO.1

main85355-12360i201409-201510

85348EJOINT, WINDSHIELD WASHER ELBOW, NO.2

main85355-20200i201409-201510

85348GJOINT, WINDSHIELD WASHER HOSE, NO.2

main85349-89122i201409-201510

85355VALVE, WINDSHIELD WASHER HOSE

main85321-28020i201409-201510

85369CLAMP

main82711-44060i201409-201510

85371HOSE, WINDSHIELD WASHER (FROM MOTOR TO JOINT)

main90099-33080i201409-201412

L=1450(*H,L=180); L=1450(*H,L=180),HEADLAMP CLEANER-WITH

main90099-62102i201412-201510

L=150; L=150,HEADLAMP CLEANER-WITH

85372HOSE, WINDSHIELD WASHER (FROM JOINT TO JOINT), NO.1

main90099-33080i201409-201510

L=1450(*H,L=1300)

85372BHOSE, WINDSHIELD WASHER (FROM JOINT TO JOINT), NO.2

main90099-33080i201409-201510

L=1450(*H,L=55)

85372HHOSE, WINDSHIELD WASHER (FROM JOINT TO JOINT), NO.3

main90099-33080i201510-201608

L=1450(*H,L=630)

85372JHOSE, WINDSHIELD WASHER (FROM JOINT TO JOINT), NO.4

main90099-62139i201810-202209

L=310

85373HOSE, WINDSHIELD WASHER (FROM JOINT TO NOZZLE)

main85370-24240i201810

L=420,RH

main90099-62087i201810

L=290,LH

85387ACLAMP, WASHER, NO.2

main82711-52090i201409-201510

85387BCLAMP, WASHER, NO.3

main82711-3A540×2i201409-201510

85388CLAMP NO.2 (FOR WINDSEIELD WASHER)

main85387-24210i201409-201510

85397SWITCH ASSY,LEVEL WARNING

main85397-52100i201409-201510

827113A640WIRE, FUSE TO FUSE(FOR COMBUSTION HEATER)

main82711-3A640

9011906767

main90119-06767

9095901568

main90959-01568
