MANIFOLD
04175GASKET KIT, TURBOCHARGER
*474
1201VENTILATION HOSE
15407PIPE SUB-ASSY, TURBO OIL INLET
*474
15407ABOLT, UNION(FOR TURBO OIL INLET PIPE)
15471GASKET, TURBO OIL INLET
*474
15472GASKET, TURBO OIL OUTLET, NO.1
*474
15481BGASKET(FOR UNION BOLT NO.1)
*474,*475
1603RADIATOR & WATER OUTLET
1703AIR CLEANER
1708VACUUM PIPING
17111MANIFOLD, INTAKE
(L)
(J)
*474
17163BRACKET, HEAT INSULATOR, NO.1
*475
*474
*474
17177GASKET, INTAKE MANIFOLD TO HEAD, NO.1
(L)
*475
*474
17179AGASKET, INTAKE MANIFOLD, NO.2
*474
17201TURBOCHARGER SUB-ASSY
*474
17265GASKET, TURBOCHARGER
*474
17271INSULATOR, TURBO, NO.1
17272INSULATOR, TURBO, NO.2
17279GASKET, TURBINE OUTLET ELBOW
2211FUEL INJECTION SYSTEM
25051CONVERTER SUB-ASSY, EXHAUST MANIFOLD
EXHAUST EMISSION CONTROL-CHINA 6B
25586INSULATOR, MANIFOLD CONVERTER, NO.1
25591BRACKET, MANIFOLD SUPPORT
8404ELECTRONIC FUEL INJECTION SYSTEM
90105C0043
main90105-C0043
90105C0081
main90105-C0081
9011610175
main90116-10175
9011910988
main90119-10988
90119C0096
main90119-C0096
90119C0125
main90119-C0125
90119C0126
main90119-C0126
90119C0467
main90119-C0467
9012606029
main90126-06029
90126C0002
main90126-C0002
90126C0014
main90126-C0014
90177C0017
main90177-C0017
9017910070
main90179-10070
9155180616
main91551-80616
9167180835
main91671-80835
9167281025
main91672-81025
40 parts on this diagram · 5 diagrams in section
