REAR DISC BRAKE CALIPER & DUST COVER

0001 1 0002 1

04466PAD KIT, DISC BRAKE, REAR

main04466-02040iZZE12#200205-200705

MARK TRW FER 4088F

main04466-52030iCDE120200205-200408

MARK AK PA511H

04479ACYLINDER KIT, DISC BRAKE, REAR

main04479-02140iZZE122..HTWCF;ZZE122..WGN..HTWC;ZZE122..ATM..SEG..SED..HTWC;ZZE12#..(GLI,XEI,XLI)..SED..HTWC200408

main04479-02220iZZE12#200205-200705

main04479-13010iCDE120200205-200408

04946SHIM KIT, ANTI SQUEAL(FOR REAR DISC BRAKE)

main04946-20020iCDE120200205-200408

main04946-52010iCDE120200408-200803

04948FITTING KIT, DISC BRAKE, REAR

main04948-02050iZZE122..HTWCF;ZZE122..WGN..HTWC;ZZE122..ATM..SEG..SED..HTWC;ZZE12#..(GLI,XEI,XLI)..SED..HTWC200408

main04948-20010iCDE120200205-200408

31478CCAP, BLEEDER PLUG(FOR REAR DISC BRAKE)

main31478-30010×2iCDE120200205-200408

main47548-02030×2iZZE12#..BZ..SED..HTWC200205-200408

47547CPLUG, BLEEDER(FOR REAR DISC BRAKE)

main47547-35020×2iCDE120200408-200803

main90080-93048×2iZZE122..WGN200205-200705

47715CPIN, CYLINDER SLIDE(FOR REAR DISC BRAKE)

main47715-02170×4iZZE12#..VEN200205-200508

main47715-20030×2iCDE120200408-200803

NO.1

main47715-20040×2iCDE120200205-200408

NO.2

47721ECOLLAR(FOR REAR DISC BRAKE CYLINDER MOUNTING)

main90389-10053×2iCDE120200205-200408

NO.2

main90389-10054×2iCDE120200205-200408

NO.1

47730BCYLINDER ASSY, REAR DISC BRAKE, RH

main47730-02130iZZE12#..BZ..SED..HTWC200205-200408

main47730-13020iCDE120200205-200408

47731BPISTON, REAR DISC BRAKE

main47731-02100×2iZZE12#..BZ..SED..HTWC200205-200408

main47731-13010×2iCDE120200205-200408

47731CRING, SET(FOR REAR DISC BRAKE PISTON)

main90522-42001×2iCDE120200408-200803

47743BSPRING, ANTI-RATTLE, NO.2(FOR REAR DISC BRAKE)

main47743-20030×2iCDE120200408-200803

47748DSPRING, ANTI-RATTLE, NO.1(FOR REAR DISC BRAKE)

main47748-20040×2iCDE120200205-200408

47748EPIN, W/HOLE(FOR REAR DISC BRAKE)

main90240-06021×4iCDE120200205-200408

47748FCLIP(FOR REAR DISC BRAKE)

main90468-12025×2iCDE120200205-200408

47750ACYLINDER ASSY, DISC BRAKE, REAR LH

main47750-02130iZZE122..WGN200205-200705

main47750-13020iCDE120200408-200803

47775DBOOT, BUSH DUST(FOR REAR DISC BRAKE)

main47775-22020×2iCDE120200408-200803

NO.1

main47775-42010×4iCDE120200205-200408

NO.2

17 parts on this diagram · 2 diagrams in section
