DISC WHEEL & WHEEL CAP

0001 1DISC WHEEL 0002 1WHEEL HUB ORNAMENT & WHEEL CA0003 1BALANCE WEIGHT

42601WHEEL, DISC

main42611-52770iNZE161..N201204-201908

15X5J, #,TYPE A:REFER ILLUST.

main42611-52A00iNRE161..E201212-201710

15X5J, #,TYPE B:REFER ILLUST.

42601AWHEEL, DISC (FOR SPARE)

main42611-52400iNRE161..4D201212-201908

16X4T,TYPE D:REFER ILLUST.

main42611-52770iNRE161,NZE161..5D201204-201908

15X5J, #,TYPE A:REFER ILLUST.

42601CNUT, HUB (FOR AXLE)

main90942-01007iNZE161..N201204-201710

TYPE A:REFER ILLUST.

main90942-01021iNRE161,NZE161201710-201908

TYPE C:REFER ILLUST.

main90942-01033iNRE161..E201212-201710

TYPE B:REFER ILLUST.

42611GVALVE (FOR TUBELESS TIRE)

main90942-05009iNRE161,NZE161201204-201908

42611JVALVE (FOR TUBELESS TIRE SPARE)

main90942-05009iNRE161,NZE161201204-201908

42652TIRE

main42652-52D70iNZE161201204-201209

175/65R15 *B/S

main42652-52E10iNZE161201204-201409

175/65R15 *D/L

main42652-52E11iNRE161,NZE161201410-201908

175/65R15 *D/L

42652ATIRE (FOR SPARE)

main42652-13120iNRE161..4D201212-201908

T125/70D16,*D/L

main42652-52D70iNZE161201204-201209

175/65R15 *B/S

main42652-52E10iNZE161..5D201204-201409

175/65R15 *D/L

main42652-52E11iNZE161..5D201410-201908

175/65R15 *D/L

7 parts on this diagram · 3 diagrams in section
