CAUTION PLATE & NAME PLATE (ENGINE)

11278PLATE, ENGINE EMISSION IDENTIFICATION

main11278-16020i4AF,2E..AE9#,EE97..RHD;2E..EE90..RHD..(LB,SED)..MTM198705-198712

SINGAPORE SPEC

11284PLATE, ENGINE BOLT INFORMATION

main11284-15010i4AF..AE92199201-199308

main11284-16020i4AGE..AE92198705-198809

main11284-16040i4AGE..AE92..SA;4AGE..AE92..GTI198809-198911

main11284-16041i4AGE..AE92199102-199308

11288PLATE, ENGINE SYSTEM

main11288-88301i4AGE..AE92198705-198908

11291PLATE, ENGINE NAME

main11291-15120i4AF..AE92199008-199308

main11291-15130i4AFE..AE95198802-198812

main11291-15140i4AFE..AE95198812-199008

main11291-16040i4AGE..AE92198705-199308

main11291-64040i1C..CE90198705-198905

11292PLATE, ENGINE NAME, NO.2

main11292-10010i2E..EE9#198705-198808

main11292-16010i4AF..AE92..4FC..XL; 4AF..AE92..RHD..GL..GEN198909-199205

SINGAPORE SPEC & W(HOT AIR INTAKE); W(HOT AIR INTAKE)

11293APLATE, ENGINE CAUTION

main11293-10012i2E..EE9#..GCC,GEN198705-198902

main11293-10020i2E..EE9#..LHD..GEN198705-199205

CHINA SPEC

main11293-11090i2E..EE90..GCC,SA198902-199006

main11293-16030i4AGE..AE92198705-198908

11294PLATE, ENGINE CAUTION, NO.2

main11294-54040i1C..CE90198705-198908

11296ALABEL, ENGINE SERVICE INFORMATION

main11296-16030i4AF..AE92..LHD..LB..5F;4AF..AE92..SED..3FC..GL;4AF..AE92..LHD..(STD,XL)198908-198912

VENEZUELA SPEC

main11296-55020i1C..CE90198705-199205

11298PLATE, EMISSION CONTROL INFORMATION

main11298-16720i4AFE..AE95198802-199009

17791LABEL, MAINTENANCE INFORMATION

main17791-16040i4AGE..AE92198908-199308

main17791-55010i1C..CE90198711-199205

main17791-64030i1C..CE90198705-198711

17792PLATE, ENGINE VACUUM HOSE INFORMATION

main17792-16390i4AFE..AE95198802-198908

main17792-16391i4AFE..AE95198908-199009

23923PLATE, FUEL SEDIMENTER CAUTION

main23923-64011i1C..CE90198705-199205

1356410010LABEL, TIMING BELT REPLACEMENT INFORMATION

main13564-10010

13 parts on this diagram · 1 diagram in section
