CAUTION PLATE & NAME PLATE (ENGINE)

11278PLATE, ENGINE EMISSION IDENTIFICATION

main11278-16020i2EL..EE80..(4DS,5DS)..RHD..MTM..(GL,XL)..GEN198505-198704

SINGAPORE SPEC

11284PLATE, ENGINE BOLT INFORMATION

main11284-16020i4AG#..AE82198708-198709

main11284-16040i4AG#..AE82198709-198807

11288PLATE, ENGINE SYSTEM

main11288-88301i4AG#..AE82198410-198807

T-VIS

11289PLATE, SPARK PLUG CAUTION

main11289-13040i4AGELC..AE82198511-198606

main11289-73020i4AGELC..AE82198606-198807

11291PLATE, ENGINE NAME

main11291-11010i2EL#..EE80198410-198612

2E

main11291-14020i2AL#..AE80198305-198807

2A

main11291-16020i4AL#..AE82198305-198612

4A

main11291-16021i4AL#..AE82198612-198807

4A

main11291-16040i4AG#..AE82198410-198807

main11291-64010i1CL..CE80198305-198505

1C

main11291-64040i1CL..CE80198505-198704

1C

main11292-10010i2EL#..EE80198410-198807

12VALVE

11296PLATE, TIMING BELT CAUTION

main11296-54010i1CL..CE80198305-198406

11298PLATE, EMISSION CONTROL INFORMATION

main11298-11030i2ELC..EE80198505-198610

main11298-11081i2ELC..EE80198610-198807

main11298-11090i2ELC..EE80198610-198807

main11298-16070i4ALC..AE82198305-198410

SWEDEN SPEC

main11298-16071i4ALC..AE82..(4DS,5D)..SDZ198505-198509

SWEDEN SPEC

main11298-16072i4ALC..AE82..(4DS,5D)..SDZ198509-198607

SWEDEN SPEC

main11298-16073i4ALC..AE82..SDZ198607-198704

SWEDEN SPEC

main11298-16080×4i4ALC..AE82198305-198311

SWITZERLAND SPEC

main11298-16081i4ALC..AE82..(4DS,5D)..SDZ198505-198704

SWITZERLAND SPEC

main11298-16091i4AL..AE82..4DS..GL..EUG198508-198704

FRG SPEC(W.GERMANY,AUSTRIA)

main11298-16170i4ALC..AE82..(3DS,5DS)..SDZ198410-198704

SWITZERLAND SPEC

main11298-16180i4ALC..AE82..(3DS,5DS)..SDZ198410-198607

SWEDEN SPEC

main11298-16330i4AL..AE82..4DS..GL..EUG198508-198704

FRG SPEC(SWISS)

main11298-16340i4AGELC..AE82198511-198807

main11298-16360i4ALC..AE82..FRG198508-198607

main11298-16361i4ALC..AE82..FRG198607-198704

main11298-16520i4ALC..AE82..5D..5F..GL..FRG; 4ALC..AE82..SED..DX..FRG198612-198704

SWEDEN SPEC

11299PLATE, IDLE ADJUSTING CAUTION

main11299-16020i2AL,4AL..AE8#..EUG198305-198704

17700DPLATE, ENGINE CAUTION

main11293-10010i2EL..EE80..EUR,GEN,SAA198410-198512

TYPE1

main11293-10011i2EL..EE80..EUR,GEN,SAA198512-198602

TYPE1

main11293-10012i2EL..EE80..EUR,GEN,SAA198602-198707

TYPE1

main11293-10020i2EL..EE80..LHD..GEN198505-198704

CHINA SPEC

main11293-10030i2ELC..EE80..FRG198605-198704

main11293-11090i2EL..EE80..SA198502-198807

main11293-11110i2EL..EE80..LHD..GEN198501-198505

CHINA SPEC

main11293-11120i2EL..EE80..GEN198505-198704

TYPE2

main11293-14030i2AL,4AL..AE8#;4ALC..AE82..SDZ198305-198807

main11293-16011i4ALC..AE82..FRG198508-198604

main11293-16030i4AG#..AE82198410-198807

main11293-64030i1CL..CE80198305-198704

17792PLATE, ENGINE VACUUM HOSE INFORMATION

main17792-11100i2ELC..EE80198505-198610

main17792-16010i4ALC..AE82;4AL..AE82..4DS..5F..GL..EUG198305-198308

main17792-16011i4ALC..AE82..SDZ198308-198601

main17792-16030i4AL..AE82..4DS..5F..GL..EUG198504-198505

FRG SPEC

main17792-16101i4ALC..AE82..FRG198508-198603

main17792-16102i4ALC..AE82..FRG198603-198704

main17792-16170i4ALC..AE82..ARL198411-198807

23923PLATE, FUEL SEDIMENTER CAUTION

main23923-64010i1CL..CE80..GEN198305-198612

main23923-64011i1CL..CE80..GEN198612-198704

11 parts on this diagram · 1 diagram in section
