FRONT TURN SIGNAL LAMP

8102FOG LAMP

→ Go to FIG 81-02

81510LAMP ASSY, FRONT TURN SIGNAL, RH

main81510-0D010iNGK12..CROSS201311-201802

81510BBULB (FOR FRONT TURN SIGNAL LAMP)

main90981-WF005×3iNGK12..CROSS201311-201802

12V 21W

81513AUNIT ASSY, FRONT TURN SIGNAL LAMP, RH

main81511-0D010iNGK12..CROSS201311-201802

81515APLUG ASSY, FRONT TURN SIGNAL LAMP

main90075-60069×2iNGK12..CROSS201311-201802

81520LAMP ASSY, FRONT TURN SIGNAL, LH

main81520-0D010iNGK12..CROSS201311-201802

81523AUNIT ASSY, FRONT TURN SIGNAL LAMP, LH

main81521-0D010iNGK12..CROSS201311-201802

9016750063

main90167-50063

8 parts on this diagram · 1 diagram in section
