DISC WHEEL & WHEEL CAP

0001 1 0002 1 0003 1

42601WHEEL, DISC

main42611-52450×4iSCP100200910

16X5.5J, #,TYPE C:REFER ILLUST.

42601AWHEEL, DISC (FOR SPARE)

main42611-1A240iSCP100200910

16X4T,TYPE B:REFER ILLUST.

42601CNUT, HUB (FOR AXLE)

main90942-01033×16iSCP100200910-201008

TYPE B:REFER ILLUST.

42611GVALVE (FOR TUBELESS TIRE)

main90942-05009×4iSCP100200910

42611JVALVE (FOR TUBELESS TIRE SPARE)

main90942-05009iSCP100200910

42652TIRE

main42652-74060×4iSCP100200910

175/65R16,*D/L

42652ATIRE (FOR SPARE)

main42652-13120iSCP100200910

T125/70D16,*D/L

7 parts on this diagram · 3 diagrams in section
