DISC WHEEL & WHEEL CAP

0001 1 0004 1 0007 1

42601WHEEL, DISC

main42611-52010×4iNCP10200406

13X5J,SILVER,TYPE A:REFER ILLUST.

main42611-52020×4iNCP10,SCP10199903-200212

13X5JJ,BLACK, #,TYPE A:REFER ILLUST.

main42611-52030×4iNCP1#,SCP10200212-200405

14X5.5J, #,TYPE A:REFER ILLUST.

main42611-52040×4iNCP1#,SCP10199903-200212

14X5.5JJ,OFFSET 45,#,TYPE B:REFER ILLUST.

42601AWHEEL, DISC (FOR SPARE)

main42611-16310iNCP1#; SCP10200212

14X4T,OFFSET 45,TYPE C:REFER ILLUST.

42601CNUT, HUB (FOR AXLE)

main90942-01007×16iNCP1#,SCP10200212

TYPE A:REFER ILLUST.

main90942-01021×16iNCP10,SCP10199903-200212

TYPE B:REFER ILLUST.

main90942-01033×16iNCP1#200212

TYPE C:REFER ILLUST.

main90942-01082×16iNCP10200308

TYPE B:REFER ILLUST.

42611GVALVE (FOR TUBELESS TIRE)

main90942-05009×4iNCP1#,SCP10200212-200405

42611JVALVE (FOR TUBELESS TIRE SPARE)

main90942-05009iNCP1#,SCP10199903-200212

42652TIRE

main42652-52030×4iNCP10..LHD199908-200212

155/80R13 79T

main42652-52031×4iNCP10..LHD200406-200508

155/80R13 79T

main42652-52040×4iNCP10..LHD199908-200212

155/80R13 82T

main42652-52041×4iNCP10..LHD200402-200405

175/65R14 82T

main42652-52050×4iNCP10,SCP10..RHD200212-200401

155/80R13

main42652-52051×4iNCP10,SCP10..RHD200402-200405

155/80R13

main42652-52060×4iNCP1#,SCP10..RHD200212-200401

175/65R14

main42652-52061×4iNCP1#,SCP10..RHD200406-200508

175/65R14

42652ATIRE (FOR SPARE)

main42652-16220iNCP1#,SCP10200212-200508

T115/70D14

7 parts on this diagram · 3 diagrams in section
