SWITCH & RELAY & COMPUTER

0001 1ENGINE & TRAMSMISSION 0002 1ENGINE & TRAMSMISSION 0003 1ENGINE ROOM 0004 1ENGINE ROOM RELAY BLOCK (RH) 0005 1ENGINE ROOM RELAY BLOCK (LH) 0006 1ENGINE ROOM RELAY BLOCK (LH) 0007 1ENGINE ROOM RELAY BLOCK (LH) 0008 1COWL 0009 1COWL 0010 1INSTRUMENT PANEL 0011 1INSTRUMENT PANEL 0012 1STEERING 0013 1STEERING 0014 1STEERING 0015 1SEAT 0016 1SEAT 0017 1DOOR & ROOF 0018 1DOOR & ROOF 0019 1DOOR & ROOF 0020 1FLOOR & BACK DOOR 0021 1FLOOR & BACK DOOR

83520GAGE ASSY,OIL PRESSURE SENDER

main83520-60050iURJ201201201-201507

main83520-60051iURJ201201508-201509

84540SWITCH ASSY, NEUTRAL START

main84540-04010iVDJ201201509

(L)

main84540-60050iURJ201201201-201509

main84540-60060iURJ201201509

main84540-71010iVDJ201201509

(J)

89465SENSOR, OXYGEN

main89465-60370iURJ201201201-201509

main89465-60470iURJ201201509

89465ASENSOR, OXYGEN NO.2

main89465-34160iURJ201201509

main89465-36040iURJ201200711-201201

89467BSENSOR, AIR FUEL RATIO

main89467-60030×2iURJ201201201-201509

main89467-60160×2iURJ201201509

main89467-60130iVDJ201201509-202112

AZERBAIJAN, GEORGIA, ARMENIA SPEC; MOROCCO SPEC; SOUTH AMERICA SPEC

89491SENSOR, ENGINE OIL LEVEL

main89491-60100iVDJ201201509

main89491-60120iURJ201200711-201008

89491AGASKET, ENGINE OIL LEVEL SENSOR

main89493-60010iURJ201,VDJ201201509

89615SENSOR, KNOCK CONTROL

main89615-20090×4iURJ201201509

8270260120BRACKET SUB-ASSY, WIRING HARNESS

main82702-60120

8271560K80BRACKET,WIRING HARNESS CLAMP

main82715-60K80

8271560K90BRACKET,WIRING HARNESS CLAMP

main82715-60K90

8271560L00BRACKET,WIRING HARNESS CLAMP

main82715-60L00

8271560L10BRACKET,WIRING HARNESS CLAMP

main82715-60L10

8271560M30BRACKET,WIRING HARNESS CLAMP

main82715-60M30

827156A650BRACKET,WIRING HARNESS CLAMP

main82715-6A650

827156A660BRACKET,WIRING HARNESS CLAMP

main82715-6A660

9011908C62

main90119-08C62

90119A0406

main90119-A0406

91511B0830

main91511-B0830

91621B0616

main91621-B0616

91621J0612

main91621-J0612

91653A0620

main91653-A0620

9167180612

main91671-80612

9167180816

main91671-80816

24 parts on this diagram · 21 diagrams in section
