FRONT DRUM BRAKE WHEEL CYLINDER & BACKING PLATE

04473CYLINDER KIT, FRONT WHEEL

main04473-37050×2iXZU410,411,420,430200010-200206

RH

sub04473-37051

main04473-37060×2iXZU410,411,420,430200010-200206

LH

sub04473-37061

04494SHOE KIT, FRONT BRAKE

main04494-37020iXZU410,411,420,430200010-200102

MARK NBK D2167

main04494-37021iXZU410,411,420,430200102-200206

MARK NBK D2167

04905CUP KIT, FRONT WHEEL CYLINDER

main04905-37050iXZU410,411,420,430200010-200206

sub04905-37052

47041PLATE SUB-ASSY, BRAKE BACKING, FRONT RH

main47041-37130iXZU410,411,420,430200010-200102

main47041-37131iXZU410,411,420,430200102-200206

sub47041-37210

47041FNUT(FOR BACKING PLATE TO STEERING KNUCKLE SETTING)

main94130-01441×8iXZU410,411,420,430200010-200206

47042PLATE SUB-ASSY, BRAKE BACKING, FRONT LH

main47042-37130iXZU410,411,420,430200010-200102

main47042-37131iXZU410,411,420,430200102-200206

sub47042-37210

47456FPLATE, FRONT BRAKE SHOE GUIDE

main47456-37010×4iXZU410,411,420,430200010-200206

47473ANUT, FRONT BRAKE SHOE ADJUSTING

main47473-37020×4iXZU410,411,420,430200010-200206

47491PLUG, HOLE(FOR FRONT BRAKE)

main47491-37070×2iXZU410,411,420,430200010-200102

RH

main47491-37080×2iXZU410,411,420,430200010-200102

LH

main47491-37090×4iXZU410,411,420,430200102-200206

47492CPLUG, HOLE(FOR FRONT BRAKE)

main47491-37090×4iXZU410,411,420,430200102-200206

main47492-37010×4iXZU410,411,420,430200010-200102

47510CYLINDER ASSY, FRONT WHEEL BRAKE, RH(FOR FRONT OR UPPER)

main47510-37070iXZU410,411,420,430200010-200206

sub47510-37071

47520CYLINDER ASSY, FRONT WHEEL BRAKE, RH(FOR REAR OR LOWER)

main47520-37090iXZU410,411,420,430200010-200206

sub47520-37091

47525PIN, WHEEL CYLINDER ADJUSTER

main47525-37010×4iXZU410,411,420,430200010-200206

47526RING, AUTOMATIC ADJUSTER

main47526-37010×2iXZU410,411,420,430200010-200206

RH

main47526-37020×2iXZU410,411,420,430200010-200206

LH

47530CYLINDER ASSY, FRONT WHEEL BRAKE, LH(FOR FRONT OR UPPER)

main47530-37070iXZU410,411,420,430200010-200206

sub47530-37071

47540CYLINDER ASSY, FRONT WHEEL BRAKE, LH(FOR REAR OR LOWER)

main47540-37090iXZU410,411,420,430200010-200206

sub47540-37091

47548CAP, BLEEDER PLUG(FOR DRUM BRAKE, FRONT)

main31478-30010×2iXZU410,411,420,430200010-200206

47551NUT, FRONT WHEEL CYLINDER ADJUSTING, RH(FOR FRONT BRAKE)

main47552-37070×2iXZU410,411,420,430200010-200206

47552NUT, FRONT WHEEL CYLINDER ADJUSTING, LH(FOR FRONT BRAKE)

main47552-37070×2iXZU410,411,420,430200010-200206

47553BOLT, FRONT WHEEL CYLINDER ADJUSTING, RH(FOR FRONT BRAKE)

main47445-37040×2iXZU410,411,420,430200010-200206

47554BOLT, FRONT WHEEL CYLINDER ADJUSTING, LH(FOR FRONT BRAKE)

main47445-37040×2iXZU410,411,420,430200010-200206

47556ESPRING, ADJUSTER LOCK(FOR FRONT BRAKE)

main47556-37010×4iXZU410,411,420,430200010-200206

47777CPROTECTOR, DUST BOOT

main47777-37010×4iXZU410,411,420,430200010-200206

9090119042

main90901-19042

9090119043

main90901-19043

9090507016

main90905-07016

9414261000

main94142-61000

9462111400

main94621-11400

9538102520

main95381-02520

9675119007

main96751-19007

30 parts on this diagram · 1 diagram in section
