CAUTION PLATE

1709CAUTION PLATE & NAME PLATE (ENGINE)

→ Go to FIG 17-09

36369LABEL, TRANSFER INFORMATION

main36369-26020iLH56,66,YH56,66198708-198908

55514APLATE, THROTTLE CONTROL NAME

main55514-95J00iLH5#..LHD..VSP;LH61..LHD..5H..(03S,U)198708-198908

DENMARK SPEC

74541PLATE, TIRE PRESSURE CAUTION

main74582-26210iLH56,66,YH56,66198708-198908

main74582-26220iLH61,YH61..J;LH51,YH51..03S,J,R198708-198908

main74582-26230iLH51,YH51..U;LH61,YH61..03S,15S,R,U198708-198908

74557APLATE, ENGINE SERVICE HOLE COVER BALANCE CAUTION

main74557-95J00iLH5#,6#,YH5#,6#198708-198908

74559APLATE, FUEL CAUTION

main74559-14030iLH5#,6#198708-198908

74582PLATE, LOAD SENSING VALVE MARKING

main47939-26120iLH51..U; YH51..U198808-198908

*FRG; NORWAY SPEC OR *FRG

main47939-26131iLH61,YH51,61..J198708-198806

main47939-26201iLH51,YH51..03S,R,U198708-198806

main47939-26211iLH61,YH61..U198808-198908

main47939-26221iLH66,YH66..J198708-198908

main47939-26231iLH56,66,YH56,66..02S,R,U198708-198908

main47939-26250iLH61..U198806-198908

DENMARK SPEC

main47939-26280iLH61,YH51,61..J198806-198908

7 parts on this diagram · 1 diagram in section
