TRANSFER LEVER & SHIFT ROD

0001 1 0002 1 0003 1 0004 1

36264PIN OR ROLLER, SHIFT INTER-LOCK

main90250-06005iRN10#,110,13#..W198808-199501

L=30.8,OD=6

main90250-10020iRN101,110,13#,VZN10#,110,13#..G,R198808-199511

L=25.7,OD=9.53

36275PLUG, SHIFT DETENT BALL SPRING

main90341-10064iRN10#,110,13#..W198808-199501

main90341-12014iRN101,110,13#,VZN10#,110,13#..G,R198808-199511

36275ASPRING, COMPRESSION (FOR SHIFT DETENT BALL)

main90501-09107iRN131,VZN10#;RN101,110,130..4FC;RN10#,110,130,VZN110,13#..G,R198908-199108

LH,INNER

main90501-13001iRN10#,110,13#..W198808-199501

L=16.5

main90501-16116iRN110,13#..4FC..SR5198808-199008

L=23

main90501-16116iRN10#,110,13#..4FC;RN101,110,13#,VZN10#,110,13#..G,R198908-199511

L=23,RH

main90501-18091iRN101,110,13#..4FC198908-199108

L=20.8,LH,OUTER

main90501-18091iRN131,VZN10#;RN101,110,130..4FC;RN10#,110,130,VZN110,13#..G,R199108-199511

L=20.8,LH

36275BBALL, SHIFT DETENT

main90360-08009iRN10#,110,13#..W198808-199501

OD=7.94,STEEL

main90360-10003iRN101,110,13#,VZN10#,110,13#..G,R198808-199511

OD=9.52,STEEL

36303KNOB SUB-ASSY, SHIFT LEVER

main36303-35050-02iRN101,110,13#,VZN100,110,13#..(G,R)..SR5198808-199108

RED,TRIM3#

sub36303-35040

main36303-35050-03iRN101,110,13#,VZN100,110,13#..(G,R)..SR5198808-199108

GRAY,TRIM1#

sub36303-35040

main36303-35050-04iRN101,110,13#,VZN100,110,13#..(G,R)..SR5198808-199108

BLUE,TRIM8#

sub36303-35040

main36303-35050-06iRN10#,110,13#..4FC;RN101,110,13#,VZN100,110,13#..(G,R)..SR5198808-199108

BROWN,TRIM4#

sub36303-35040

main36303-35060-02iRN101,110,13#..W..SR5198808-199108

RED,TRIM3#

sub36303-35060

main36303-35060-03iRN101,110,13#..W..SR5198808-199108

GRAY,TRIM1#

sub36303-35060

main36303-35060-04iRN101,110,13#..W..SR5198808-199108

BLUE,TRIM8#

sub36303-35060

main36303-35060-06iRN101,110,13#..W..SR5198808-199108

BROWN,TRIM4#

sub36303-35060

main36303-35070-01iRN10#,110,VZN10#,110..(G,R)..DLX198808-199108

BLACK,TRIM1#,3#,4#,8#

main36303-35080-01iRN10#,110..W..DLX198808-198908

BLACK,TRIM1#,3#,4#

main36303-35080-01iRN10#,110..W..DLX198908-199108

BLACK,TRIM1#,3#,4#,8#

main36303-35100iRN10#,110,VZN10#,110..5F..DLX199108-199501

main36303-35110-03iRN13#;RN101,110..4FC;VZN110,13#..R..SR5199108-199208

GRAY,TRIM1#

sub36303-35110

sub36303-35140

main36303-35110-04iRN13#;RN101,110..4FC;VZN110,13#..R..SR5199108-199202

BLUE,TRIM8#

sub36303-35110

sub36303-35140

main36303-35110-E0iRN13#;VZN13#..R199108-199308

TAN,TRIM4#

sub36303-35110

sub36303-35140

main36303-35110-E1iRN13#;VZN13#..R199308-199511

OAK,TRIM4#

sub36303-35110

sub36303-35140

main36303-35110-R9iRN13#;RN101,110..4FC;VZN110,13#..R..SR5199202-199511

MEDIUM BLUE,TRIM8#

sub36303-35110

sub36303-35140

main36303-35110-S4iRN13#;RN101,110..4FC;VZN110,13#..R..SR5199208-199511

MEDIUM GRAY,TRIM1#

sub36303-35110

sub36303-35140

main36303-35130-B0iVZN13#..R199108-199511

LEATHER,GRAY,TRIM1#

main36303-35130-E2iVZN13#..R199308-199511

LEATHER,OAK,TRIM4#

36304RETAINER SUB-ASSY, TRANSFER CONTROL SHIFT LEVER

main36304-35040iVZN10#,110,13#..R198808-199511

sub36304-35H01

sub36304-35H21

sub36304-35H27

main36304-35050iRN101,110,13#..G198808-199511

sub36304-35H02

sub36304-35H03

sub36304-35H04

sub36304-35H05

sub36304-35H06

sub36304-35H07

sub36304-35H08

sub36304-35H09

sub36304-35H10

sub36304-35H11

sub36304-35H12

sub36304-35H22

sub36304-35H23

sub36304-35H24

sub36304-35H25

sub36304-35H26

36311BPIN, SLOTTED SPRING (FOR TRANSFER SHIFT FORK)

main90254-05001iRN10#,110,13#,VZN10#,110,13#..R,W198808-199511

L=22

36311CSPRING, COMPRESION (FOR SHIFT FORK)

main90501-20088iRN101,110,13#,VZN10#,110,13#..G,R198808-199511

36311FFORK, TRANSFER GEAR SHIFT, NO.1

main36311-35010iRN10#,110,13#..W198808-199501

main36311-35020iVZN10#,110..R..DLX198808-199511

main36311-35030iRN110,13#..4FC..SR5198908-199511

W(*ADD)

main36311-35030iRN101,110,13#,VZN100,110,13#..(G,R)..SR5198808-199008

36311GRING, SHAFT SNAP (FOR TRANSFER GEAR SHIFT FORK)

main90520-13002iRN101,110,13#..G198808-199511

36312FFORK, TRANSFER GEAR SHIFT, NO.2

main36312-35020iRN10#,110,13#..W198808-199501

main36312-35030iRN101,110,13#,VZN10#,110,13#..G,R198808-199108

main36312-35040iRN131,VZN10#;RN101,110,130..4FC;RN10#,110,130,VZN110,13#..G,R199108-199511

36313FSHAFT, TRANSFER FRONT DRIVE SHIFT FORK

main36313-35040iVZN10#,110,13#..R198808-199511

main36313-35050iRN101,110,13#..G198808-199511

main36313-35060iRN10#,110,13#..W198808-199501

36314SHAFT, TRANSFER HIGH AND LOW SHIFT FORK

main36314-35060iVZN10#,110,13#..R198808-199108

main36314-35070iRN10#,110,13#..G198808-199108

main36314-35080iRN10#,110,13#..W198808-199501

main36314-35090iRN10#,110,13#..4FC198908-199106

main36314-35091iRN101,110,13#..4FC199106-199108

main36314-35110iRN131;RN10#,110,130..G;RN101,110,130..4FC199108-199511

main36314-35130iVZN10#,110,13#..R199108-199511

36315APIN, TRANSFER GEAR SHIFT FORK SHAFT

main36315-35010iRN101,110,13#..G198808-199511

36316HEAD, TRANSFER GEAR SHIFT, NO.2

main36316-35020iRN101,110,13#..G198808-199511

36317CSTOPPER, TRANSFER SHIFT SHAFT

main36317-35010iVZN10#,110,13#..R198808-199403

sub36317-35011

main36317-35010iRN101,110,13#..G198808-199403

NO.1

sub36317-35011

main36317-35011iRN101,110,131..4FC199403-199511

NO.1

main36317-35011iRN10#,110,13#..G199403-199511

N0.1

main36317-35020iRN101,110,13#..G198808-199511

NO.2

36318BOOT, TRANSFER FRONT DRIVE SHIFT

main33555-20060iRN10#,110,13#..W198808-199501

main33555-35090iRN10#,110,13#..4FC;RN10#,110,13#,VZN10#,110,13#..G,R198808-199511

36321BRING, HOLE SNAP (FOR TRANSFER FRONT DRIVE SHIFT LEVER)

main90521-49003iVZN105,110,13#..R;RN10#,110,13#,VZN100198808-199511

36349SPRING, TRANSFER SELECT RETURN

main36349-35010iVZN10#,110,13#..R198808-199511

main36349-35020iRN10#,110,13#..G;RN10#,110,13#..4FC198808-199511

main36349-35040iRN10#,110,130..W199110-199501

36360GLEVER ASSY, TRANSFER HIGH & LOW SHIFT

main36360-35070iRN10#,110,13#,VZN10#,110,13#..G,R198808-199511

sub36360-35071

sub36304-35051

main36360-35090iRN10#,110,13#..W198808-199501

main36360-35130iRN10#,110,13#..4FC198908-199511

sub36360-35131

sub36304-35051

9011908276

main90119-08276

21 parts on this diagram · 4 diagrams in section
