DISC WHEEL & WHEEL CAP
42601AWHEEL, DISC (FOR SPARE)
14X5.5J,TYPE A,SILVER
14X5.5JJ,TYPE A,BLACK
14X5.5JJ,TYPE B,SILVER M
42601CNUT, HUB (FOR AXLE)
CAP NUT
42601DWEIGHT, BALANCE (FOR DISC WHEEL)
10G,T=8.6
20G,T=8.6
30G,T=8.6
40G,T=9.5
50G,T=9.5
60G,T=9.5
70G,T=9.5
80G,T=9.5
20G,T=8
30G,T=10
40G,T=9.5
50G,T=9.5
60G,T=9.5
70G,T=9.5
80G,T=9.5
10G,T=7.5
42601FWHEEL, DISC (FOR FRONT)
14X5.5J,TYPE A,SILVER
14X5.5JJ,TYPE A,BLACK
14X5.5JJ,TYPE B,SILVER M
42601RWHEEL, DISC (FOR REAR)
14X5.5J,TYPE A,SILVER
14X5.5JJ,TYPE A,BLACK
14X5.5JJ,TYPE B,SILVER M
42611GVALVE (FOR TUBELESS TIRE)
42611JVALVE (FOR TUBELESS TIRE SPARE)
42652TIRE
175SR14
175R14C,*B/S; 175R14C,*B/S,AUSTRIA SPEC
195/70HR14
42652ATIRE (FOR SPARE)
175SR14
175R14C,*B/S; 175R14C,*B/S,AUSTRIA SPEC
195/70HR14
9 parts on this diagram · 2 diagrams in section
