OIL FILTER

0001 1 0002 1W/O(OIL COOLER) 0003 1 0004 1 0005 1

15600AUNION(FOR OIL FILTER)

main15116-54021i2C..CE100199205

main90404-19001i4AFE..AE101..LHD199505

W/O(OIL COOLER)

main90404-19007i2E,4EFE..EE10#199205-199704

main90405-19003i4AFE,7AFE..AE10#199205

15600BRING, O, NO.1(FOR OIL FILTER)

main15188-11010i4AFE,7AFE..AE10#199205

15601FILTER SUB-ASSY, OIL

main90080-91058i4AFE,7AFE..AE10#199301

(L)

main90915-10001i2E,4EFE..EE10#; 4AFE,7AFE..AE10#199205

(J)

main90915-30001i2C..CE100199205-199505

main90915-30003i2C..CE100199505

15604VALVE SUB-ASSY, OIL SAFETY

main15131-38030i4AFE,7AFE..AE10#199205

15609BRACKET SUB-ASSY, OIL FILTER

main15608-64040i2C..CE100199205-199505

main15608-64041i2C..CE100199505

main15670-16030i4AFE,7AFE..AE10#199205

15609BUNION(FOR OIL FILTER BRACKET)

main90029-40004i4AFE,7AFE..AE10#199205

15609CGASKET(FOR OIL FILTER BRACKET UNION)

main90430-14235×2i4AFE,7AFE..AE10#199205

15609DPLUG, W/HEAD STRAIGHT SCREW(FOR OIL FILTER BRACKET)

main15133-20010i4AFE,7AFE..AE10#199205

main90344-53002×5i2C..CE100199205

15609EGASKET, W/HEAD STRAIGHT SCREW PLUG

main15134-20010i4AFE,7AFE..AE10#199205

15609FSPRING(FOR OIL FILTER BRACKET)

main15132-21010i4AFE,7AFE..AE10#199205

15609GBOLT, UNION(FOR OIL FILTER BRACKET)

main90401-14003i4AFE,7AFE..AE10#199205

9010906088

main90109-06088

9020119272

main90201-19272

13 parts on this diagram · 5 diagrams in section
