FRONT AXLE HOUSING & DIFFERENTIAL

0001 1 0002 1 0003 1 0004 1 0005 1

31105CASE SUB-ASSY, TRANSAXLE(MTM)

main31105-16011iAL11..MTM197901-198204

sub31105-16012

31105APLUG, TIGHT(FOR FRONT TRANSAXLE CASE)

main90331-29001iAL11..4F197901-198204

31105BBOLT, HEXAGON(FOR DIFFERENTIAL BEARING CAP SETTING)

main90105-10008iAL11..MTM197901-198204

31105CPIN, STRAIGHT(FOR TRANSAXLE CASE)

main90250-10232iAL11..MTM197901-198204

31110APLUG(FOR DIFFERENTIAL FILLER)

main90341-18002iAL11197901-197908

main90341-18006iAL11..MTM197908-198204

31110BPLUG(FOR DIFFERENTIAL DRAIN)

main90341-18057iAL11..MTM197901-198204

31110CGASKET(FOR DIFFERENTIAL FILLER)

main12157-10010iAL11..MTM197901-198204

31110DGASKET(FOR DIFFERENTIAL DRAIN)

main12157-10010iAL11..MTM197901-198204

31283RETAINER, CLUTCH RELEASE BEARING HUB

main31283-16010iAL11..MTM197901-198204

33101FRING, O(FOR INPUT FRONT)

main90301-54002iAL11..MTM197901-198204

41110FCARRIER ASSY, DIFFERENTIAL, FRONT

main41110-16020iAL11197901-197906

*AXC=Y302,R=41:11

sub41110-16021

main41110-16021iAL11..MTM197906-198204

*AXC=Y302,R=41:11

main41110-16050iAL11..3FC..EUR198008-198204

*AXC=Y302,R=3.727

main41110-16050iAL11..3FC197908-198008

main41110-16070iAL11..3FC198008-198204

*AXC=Y372,R=3.583

41181COVER, FRONT DIFFERENTIAL CARRIER

main41181-16010iAL11197901-197906

sub41181-16020

main41181-16020iAL11197906-198204

41181AGASKET, FRONT DIFFERENTIAL CARRIER COVER

main41182-16010iAL11197901-198204

9033120001

main90331-20001

9161140612

main91611-40612

9161140820

main91611-40820

9161961250

main91619-61250

17 parts on this diagram · 5 diagrams in section
