BACK DOOR LOCK & HANDLE

68801AHINGE SUB-ASSY, BACK DOOR, UPPER

main68801-0D120×2iKSP130,NHP130,NLP130,NSP130201109-201407

PAD T=1.0

sub68801-0H100

68838PAD, BACK DOOR HINGE, NO.1

main68838-74020×2iKSP130,NHP130,NLP130,NSP130201109

T=0.5

main68838-74030×2iKSP130,NHP130,NLP130,NSP130201109

T=1.0

68945BRACKET, BACK DOOR DAMPER STAY, UPPER RH

main68945-52110iKSP130,NHP130,NLP130,NSP130201107

68946BRACKET, BACK DOOR DAMPER STAY, UPPER LH

main68945-52110iKSP130,NHP130,NLP130,NSP130201107

68947BRACKET, BACK DOOR DAMPER STAY, LOWER RH

main68947-52020iKSP130,NHP130,NLP130,NSP130201107

68948BRACKET, BACK DOOR DAMPER STAY, LOWER LH

main68948-52020iKSP130,NHP130,NLP130,NSP130201107

68950CSTAY ASSY, BACK DOOR, RH

main68950-0W640iKSP130,NLP130,NSP130..MTM201107-201302

main68950-0W641iKSP130,NLP130,NSP130..MTM201302

main68950-0W660iNHP130,NSP130..CVFC201107-201302

main68950-0W661iNHP130,NSP130..CVFC201302

main68950-0W650iNHP130..ACTIV201204-201302

HV SIMPLE PACKAGE

sub68950-0W651

68960STAY ASSY, BACK DOOR, LH

main68960-0W620iKSP130,NLP130,NSP130..MTM201107-201302

main68960-0W621iKSP130,NLP130,NSP130..MTM201302

main68960-0W640iNHP130,NSP130..CVFC201107-201302

main68960-0W641iNHP130,NSP130..CVFC201302

main68960-0W630iNHP130..ACTIV201204-201302

HV SIMPLE PACKAGE

sub68960-0W631

69350PLOCK ASSY, BACK DOOR, W/COURTESY LAMP SWITCH

main69350-02090iKSP130,NHP130,NLP130,NSP130201402-201407

main69350-0D131iKSP130,NHP130,NLP130,NSP130201201-201209

main69350-0D132iKSP130,NHP130,NLP130,NSP130201210-201402

main69350-52390iKSP130,NLP130,NSP130201107-201112

sub69350-52391

69430CSTRIKER ASSY, BACK DOOR LOCK

main69430-02030iKSP130,NHP130,NLP130,NSP130201402

main69430-0D070iKSP130,NHP130,NLP130,NSP130201201-201402

main69430-52050iKSP130,NLP130,NSP130201107-201201

9010506184

main90105-06184

90105W0030

main90105-W0030

90119W0129

main90119-W0129

90148W0004

main90148-W0004

9017908096

main90179-08096

15 parts on this diagram · 1 diagram in section
